Icom IC-i7410 Instruction Manual page 94

10
SET MODE
■ Set mode description (Continued)
17. Tuner (PTT Start)
Whenever you push [PTT], the internal or external an-
tenna tuner automatically starts tuning if the operating
frequency is changed by more than 1% from the last-
tuned frequency.
• OFF : Tuning starts only when [TUNER] is pushed.
• ON : (Internal antenna tuner) Tuning starts when
you push [PTT] on a new frequency, if the in-
ternal antenna tuner is ON.
(External antenna tuner) Tuning always starts
when you push [PTT] on a new frequency, re-
gardless of whether the external antenna tuner
is ON or OFF.
18. Tuner Preset Clear
Select the desired antenna.
The selected antenna's preset memory* is cleared by
holding down [CLR](F-4) for 1 second.
* The variable capacitor settings are memorized as a
preset point for each frequency range (100 kHz steps)
after the tuner matches an antenna.
• CLR ANT1 : The preset memory of [ANT1]'s antenna
is cleared.
• CLR ANT2 : The preset memory of [ANT2]'s antenna
is cleared.
19. [ANT] Switch
Set the antenna switch function to Auto, Manual or OFF.
When you change the operating frequency, this func-
tion will automatically select the correct antenna, or you
must do it manually.
• OFF : [ANT•METER] does not function. The
[ANT1] connector is always selected.
• Manual : You must manually change the antenna by
pushing [ANT•METER].
• Auto : The antenna memorized by the band mem-
ory is automatically selected. You can also
manually change the antenna by pushing
[ANT•METER].
87
20.
(Default: OFF)
Adjust the speech audio output level to between 0%
(no output) and 100% (maximum output).
21.
Select English or Japanese as the speech language.
22.
Select HIGH (faster) or LOW (slower) speech speed.
23.
The signal level announcement with the voice synthe-
sizer can be turned ON or OFF.
• OFF : The signal level is not announced. Operating
• ON : The signal level and the operating frequency
24.
Turn the Operating Mode Speech function ON or
OFF.
When this function is ON, the selected operating mode
is verbally announced when a mode switch is pushed.
• OFF : The operating mode Speech function is OFF.
• ON : The operating mode Speech function is ON.
(Default: Auto)
25.
Set the number of available memo pads to 5 or 10.
See page 74 for details.
26.
Set the Auto Tuning Step function for [DIAL]. When
rapidly rotating [DIAL], the tuning step automatically
changes as selected.
There are two types of auto tuning steps: LOW (Faster)
and HIGH (Fastest).
• OFF : Auto tuning step is turned OFF.
• LOW : Approximately 2 times faster.
• HIGH : Approximately 5 times faster when the tuning
SPEECH Level
SPEECH Language
SPEECH Speed
SPEECH S-Level
frequency is announced.
are announced.
SPEECH [MODE] SW
Memopad Numbers
MAIN DIAL Auto TS
step is set to 1 kHz or smaller steps; approxi-
mately 2 times faster when the tuning step is
set to 5 kHz or larger steps.
(Default: 50%)
(Default: English)
(Default: HIGH)
(Default: ON)
(Default: OFF)
(Default: 5)
(Default: HIGH)
