8. READ the instructions of the test equipment throughly before connecting it to the transceiver. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.
SECTION 2. INSIDE VIEWS • THE VIEW FROM THE BOTTOM OF CHASSIS VARIABLE CAPACITORS NETWORK UNIT YGR AMP (IC201) USB HUB PRE-AMP (IC902) (Q532) BPF UNIT BPF UNIT USB CODEC (IC551) PRE-AMP (Q511, Q512) USB BRIDGE (IC901) 5 V REGULATOR BUS BUFFER (IC121) (IC901)
Page 6
• DISPLAY UNIT FRONT CPU CLOCK (X401) MULTIPLEXER (IC351) CMOS LOGIC IC MULTIPLEXER (IC271) (IC371) FRONT CPU (IC401) LCD DRIVER (IC521) LCD CONTRAST DC AMP (IC151) LCD CONTRAST DC AMP (IC152) LCD DRIVER (IC561) LCD DRIVER (IC501) LCD DRIVER (IC541) PTT SW BUFFER (Q501) 2 - 2...
Page 7
• MAIN UNIT (TOP VIEW) DC-DC CONVERTER (IC2001, D2001, D2002) D/A CONVERTER S/P CONVERTER (IC3204) (IC3201) DC AMP (IC3271) CURRENT AMP (IC3251) 3RD TX IF MIXER (IC3621) DC AMP (IC3675) AGC BUFFER AGC LEVEL DETECT (IC4601) (IC3532) (IC3401) VOX LPF (IC3452) VOX BUFFER (IC4403)
Page 8
• MAIN UNIT (BOTTOM VIEW) MULTIPLEXER (IC1161) CMOS BUFFER (IC6101) CMOS BUFFER CMOS BUFFER (IC6103) (IC6102) TX AF BUFFER (IC4401) AF AMP (IC4483) AF LPF AF BUFFER (IC4402) (IC4482) AF LPF (IC4603) RX AF BUFFER (IC4602) X3R3V LINE SW (IC2101) AF AMP AGC AMP (IC4661)
Page 9
• PA-A UNIT S/P CONVERTER (IC432) POWER AMP (Q242) POWER AMP (Q241) BIAS CONTROLLER (IC301) DC-DC CONVERTER (IC131) DRIVE AMP (Q222) DRIVE AMP (Q221) DC AMP PRE-DRIVE AMP (IC371) (Q201) D/A CONVERTER (IC431) 2 - 5...
Page 10
• CTRL UNIT TX POWER DETECTOR (D602) PHASE DETECTOR (IC111) DC AMP (IC41) TUNER CPU DC AMP (IC701) (IC131) +5V LINE REGULATOR (IC801) 2 - 6...
SECTION 3. CIRCUIT DESCRIPTION 3-1 RECEIVER CIRCUITS ANTENNA SWITCHING CIRCUITS (CTRL UNIT) PREAMPLIFIER CIRCUITS (BPF UNIT) RX signal from the antenna connector [ANT1] (J1) or [ANT2] The RX signal from the BPF circuits is applied to or (J2) is passed through the antenna switch (RL501), current bypassed the preamplifi...
Page 12
1ST RX IF CIRCUITS (RF-A UNIT) 2ND RX IF CIRCUITS (RF-A UNIT) The RX signal from the BPF UNIT is passed through the The 1st RX IF signal from the 1st RX IF circuits is divided LPF, which removes unwanted signals (60 MHz and higher), into two paths, and then each signal is applied to the 2nd RX and then applied to the 1st RX IF mixer (Q721–Q724) to IF mixers (the image reduction mixers;...
RX AF CIRCUITS (CONNECT UNIT) 3-2 TRANSMITTER CIRCUITS • AUDIO OUTPUT FROM THE SP/HEADPHONES TX AF CIRCUITS (MAIN UNIT) The AF signal from the demodulator circuits is applied to The audio signal from the microphone (MIC signal) is the AF AMP (IC221), through the squelch gate (Q231). applied to the MAIN UNIT, through the MICROPHONE The amplifi...
3RD TX IF AND 2ND TX IF CIRCUITS (MAIN UNIT) BPF CIRCUITS The 3rd TX IF signal from the modulation circuits is amplifi ed The TX signal from the 1st TX IF circuits is passed through by two AMPs (IC4661 and IC3601), and then applied to an LPF or one of BPFs, depending on the transmitting the 3rd TX mixer (IC3621) to be mixed with the 3rd TX LO frequency, to remove unwanted signals contained in the TX...
Page 15
TX AMPLIFIER CIRCUITS (PA-A UNITS) ANTENNA TUNING AND SWITCHING CIRCUITS The TX signal from the BPF UNIT is sequentially amplifi ed (CTRL UNIT) by the pre-drive AMP (Q201), drive AMP (Q221, Q222), and The TX signal from the PA-A UNIT is passed through power AMP (Q241, Q242).
3-3 FREQUENCY SYNTHESIZER (PLL UNIT) REFERENCE FREQUENCY OSCILLATOR CIRCUIT The 2nd RX LO signal is fi ltered by the crystal fi lter (FI981), and then applied to the RF-A UNIT as the 2nd RX LO signal. The cr ystal oscillator (X151) generates the 32 MHz reference frequency signal.
3-4 CPU PORT ALLOCATIONS • MAIN CPU (MAIN UNIT: IC1201) Line Line Description Description Name Name Noise pulse. VBUS connection detect for USB HUB. VBUS H=USB connection detected. Microphone PTT input. PSENI H=While transmitting. MIC signal detect. DAVOX H=Input detect. Bus control "Wait"...
Page 18
• FRONT CPU (DISPLAY BOARD: IC401) 3-5 VOLTAGE BLOCK DIAGRAM Line Description DC-IN H3.3V H3.3V “PWRK ” FRONT FRONT Name 13.8V POWER SW LCD contrast control. (segement area) CNT2V (1–2.3 V) “PWRS” LCD contrast control. (dot area) CNT1V (1–2.3 V) H14V Front CPU Reset.
SECTION 4. ADJUSTMENT PROCEDURE 4-1 PREPARATION ¤ REQUIRED EQUIPMENTS EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE Modifi ed 3.5 mm (1/8’’) monoral plug Audio generator Frequency range : 300–3000 Hz Short plug (See the illust below) (AG) Output level : 1–500 mV RF voltmeter Measuring range...
4-2 ADJUSTMENTS ON THE PLL UNIT TRANSCEIVER'S MEASURE ADJUST ADJUSTMENT ITEM OPERATION VALUE CONDITION POINT POINT REFERENCE 1 • Frequency: 14.10000 MHz • Connect a frequency counter to J571 (Verify) 64.000000 MHz FREQUENCY • Mode: USB J571. (±300 Hz) SIGNAL •...
Page 21
• THE LOCATION OF ADJUST/CHECK POINTS ON THE PLL UNIT R902 C901 R901 R911 R981 R805 C810 Q802 R904 FI981 L981 Q903 R809 R982 R900 L801 R984 L803 C805 R986 Q803 C803 R802 Q902 Q900 R807 Q701 L703 L850 Q852 RX 2ND LO LEVEL R732 C716...
Page 22
4-3 ADJUSTMENTS ON THE MAIN UNIT TRANSCEIVER'S MEASURE ADJUST ADJUSTMENT ITEM OPERATION VALUE CONDITION POINT POINT PRESET • Receiving – – L3652 Screw the core all the way inside the coil. • THE LOCATION OF ADJUST/CHECK POINTS ON THE MAIN UNIT Preset point C3692 C3694...
Page 23
• THE LOCATION OF ADJUST/CHECK POINTS ON THE RF-A UNIT R1276 IMAGE REJECTION Adjust point IMAGE REJECTION Adjust point C1121 MP1201 RX SENSITIVITY Adjust point MP1101 EP913 EP911 MP651 TX POWER Adjust point J501 TO BPF MIXER BALANCE/ RX SENSITIVITY RX SUPRIOUS Adjust point L723...
Page 24
4-5 ADJUSTMENTS ON THE CTRL UNIT TRANSCEIVER'S MEASURE ADJUST ADJUSTMENT ITEM OPERATION VALUE CONDITION POINT POINT TUNER REFERENCE 1 • Frequency: 3.55 MHz • Connect a 50 ohms dummy load CP31 Min. voltage • [TUNER]: Through to [ANT1]. • TX power: Max. 1) Turn OFF the power.
4-6 ADJUSTMENTS ON THE FUNCTION DISPLAY 1) Connect the short plug (Page 4-1) to [REMOTE], and while holding down [MENU] and [SSB], turn ON the power. 2) The main adjustment menu appears. ¤ MAIN ADJUSTMENT MENU R E F Select the ID adjustment (See below) Select the receive adjustment (Page 4-10) Select the transmit adjustment (Page 4-8) Select the reference frequency/APC reference adjustment (Page 4-9)
¤ TRANSMIT ADJUSTMENTS Stores the value and move to the next item. Reterns to the previous screen. MENU Starts the transmit adjustment. TRANSCEIVER'S MEASURE ADJUST ADJUSTMENT ITEM OPERATION VALUE CONDITION POINT POINT PREPARATION • Connect an AG and millivoltmeter – –...
¤ REFERENCE ADJUSTMENTS • Reference adjustment menu. R E F A P C V C C Reterns to the previous screen. MENU Select the APC reference adjustment. Select the reference frequency adjustment. • REFERENCE FREQUENCY ADJUSTMENT Stores the value and move to the next item. Reterns to the previous screen.
¤ RECEIVE ADJUSTMENTS Stores the value and move to the next ite Reterns to the previous screen. MENU Starts the receiveadjustment. TRANSCEIVER'S MEASURE ADJUST ADJUSTMENT ITEM OPERATION VALUE CONDITION POINT POINT PREPARATION • Connect an SSG to [ANT1], and – –...
Page 62
• FRONT UNIT MP65(C)×4 MP66(C) MAIN UNIT MP41(C)×9 JACK UNIT EP2(F) MP34(F)×10 EP3(F) J1(MIC) MIC UNIT MP32(F)×17 MP2(F) DISPLAY UNIT MP454(DI) MP453(DI) MP455(DI) DS451(DI) DS111(DI) MP37(F) MP451(DI) MP38(F) MP452(DI) VR-B UNIT MP456(DI)×4 VR-B UNIT MP9(F) MP6(F) MP40(F) MP10(F) UNIT ABBREVIATIONS MP12(F) (C)= CHASSIS PARTS MP11(F)
The combination of top side and bottom side of this SECTION 7. BOARD LAYOUTS • DISPLAY BOARD (TOP VIEW) MP451 S731 POWER S601 S611 S621 S631 SPLIT POWER S602 S612 S622 S632 S732 TRANSMIT TRANSMIT S603 S613 S623 S633 S733 TUNER S604 S614...
Page 65
The combination of top side and bottom side of this • DISPLAY BOARD (BOTTOM VIEW) R262 R611 R634 R622 R612 R633 C375 R623 R613 R632 C379 C374 R624 R614 R264 C1221 C378 C373 R601 C407 C377 C372 R602 C408 C376 C371 R603 C355...
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • PLL UNIT (TOP VIEW) L952 L951 R907 IC122 C982 R902 C901 R901 R911 R981 R805 C810 Q802 R904 FI981 L981 R809 Q903 R982...
Page 67
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • PLL UNIT (BOTTOM VIEW) 7 - 4...
Page 68
The combination of top side and bottom side of this • MAIN UNIT (TOP VIEW) TO CTRL J3203 C4005 C4001 C4065 C3692 C3694 C4004 L3693 C4064 C4042 C4034 C4028 C4025 R3675 C3693 C4062 C4033 C4032 C4029 C4026 C4048 J3203 C3696 C3695 TO RF-A C3401...
Page 69
The combination of top side and bottom side of this • MAIN UNIT (BOTTOM VIEW) C6101 R4520 R4521 C4503 C6103 C4502 R3404 R4505 R4504 C3402 R3406 R1312 R3664 C3451 C3442 C3404 L3401 C3452 R3662 C3455 R3409 R4603 C3441 D3532 C4489 R4507 C3456 R3445...
The combination of top side and bottom side of this [ALC] [SEND] • CONNECT UNIT [KEY] [REMOTE] [EXT-SP] (TOP VIEW) [USB] [ACC] D902 D901 C924 Q1111 J611 J101 J751 Q1106 C902 R100 C1114 C907 R921 R1101 IC902 RL1401 J1101 EP602 C621 D622 R622...
Page 71
The combination of top side and bottom side of this [EXT-SP] [REMOTE] [SEND] [ALC] [KEY] • CONNECT UNIT (BOTTOM VIEW) C1111 C1115 L1109 C1112 R1111 R1109 EP751 L1401 C1401 D1106 EP1106 L1107 R750 R1107 C754 C1116 C753 L1102 EP1104 EP753 C1405 C1101 C909...
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • PA-A UNIT (TOP VIEW) C1253 C1258 C1252 Q1255 Q1257 Q1253 Q1263 Q1251 Q1259 Q1261 IC432 Q1256 Q1258 Q1254 Q1264 Q1252 Q1260 Q1262 C505...
Page 73
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • PA-A UNIT (BOTTOM VIEW) C519 C510 C520 C521 C551 C612 R122 C607 R344 C604 C608 R752 R346 R123 C603 R751 C714 C463 R363...
Page 74
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • VR-B UNIT (TOP VIEW) • VR-A UNIT (TOP VIEW) • PBT UNIT • VR-C UNIT (TOP VIEW) (TOP VIEW) B-7162B VR-B SX3183=M-CH B-7165D...
Page 75
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • VR-B UNIT • VR-A UNIT (BOTTOM VIEW) (BOTTOM VIEW) • PBT UNIT • VR-C UNIT (BOTTOM VIEW) (BOTTOM VIEW) • NETWORK UNIT (BOTTOM VIEW) MP105 7 - 12...
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • CTRL UNIT (TOP VIEW) V100 V105 V110 V115 V120 V125 V130 V135 V140 V145 V150 V155 V160 V165 V170 IC41 C1001 R1008 C1002...
Page 77
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • CTRL UNIT (BOTTOM VIEW) V170 V165 V160 V155 V150 V145 V140 V135 V130 V125 V120 V115 V110 V105 V100 IC31 C121 C101 D101...
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • BPF UNIT (TOP VIEW) J141 C140 J201 R201 L134 L141 L133 C201 Q132 C131 R203 R141 C203 C139 C170 TO PA-A TO CTRL IC201 C143...
Page 79
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • BPF UNIT (BOTTOM VIEW) D134 C132 R133 C161 R162 L135 C141 R161 R163 L535 L531 R538 R303 D552 C552 D551 C302 L511 R518...
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • RF-A UNIT (TOP VIEW) C1011 R1022 J1011 MAIN L912 R1077 FI911 C1051 L915 L1051 Q741 R1078 L1032 C916 C1078 C613 MP1071 C1032 RF-A...
Page 81
The combination of this page and next page shows the top side and bottom side of actual P.C. board. • RF-A UNIT (BOTTOM VIEW) R1011 C781 R763 R761 R762 R781 D781 D601 C1072 C1012 R742 C601 MP911 C1001 Q1072 C1077 D911 R601 Q1071...
• MAIN UNIT (MAIN-1) 3R3V 3R3V M DAT M DAT M STB MSTB ASTB ASTB H3R3V RASTB CI-V RASTB 3R3V C1161 3R3V 3R3V Q1001 3R3V I C1161 CCSTB C1001 CCSTB DMG504010 REFL CASTB CASTB MP1Y2 HTHML PAASTB R1284 PAASTB I C1001 MP1YL ALCL VBUS...
Page 93
• MAIN UNIT (MAIN-2) R2009 R2010 4.7k MAIN-1 MP2002 3183 ISET R191 ISET I KEY# R192 3.33 IKEY# EP51 3R3V ISTA R193 ISTA M PZ2012S221A DRESL5 R194 13.66 EP52 -12V THRI_ R195 THRI_ M PZ2012S221A C2007 100P EP2001 C2003 I C2001 L2002 REFL_ R197...
Page 94
• MAIN UNIT (MAIN-3) I C3532 I C3523 IC3523 MAIN-2 TS522ID 3R3V NJM072BM 3R3V NJM072BM -12V MDRIF C3433 C3543 KDS4148U D3531 R3547 270P J3203 IC3523 R3433 R3539 R3541 C3545 R3552 MAGC_DET 330k HRIF 8.2k R3548 MAGC_DET R3545 I C3532 MAIN-1 RB706F D3533 C3432...
Page 95
• MAIN UNIT (MAIN-4) R4001 D1R2V R4002 3R3V MAIN-2 R4005 4 7 k I C 3 9 5 1 I C 3 9 5 2 M1R2V / HOLD OU T S-80811CNNB E P 4 0 0 1 MPZ1608S221A SN74AHC1G08DCK3 C4010 C4055 VDDINT VDDINT...
Page 96
• MAIN UNIT (MAIN-5) 3R3V -12V AVOXL DTAF SPEECH 3.29 R4447 R4520 MDRAF MAIN-3 MAGC C4437 4.7k R4518 MAIN-2 I C4483 I C4482 R4404 680P I C4401 TS522ID NJM4558M DTAF C4421 R4432 I C4402 R4448 R4521 R4519 I C4401 3.29 TS522ID R4403 R4423...
Page 97
• MAIN UNIT (MAIN-6) • RF-A UNIT (RF-1) 4.90V DRES_ HPR2S R351 _HPR2S I C303 HPR1S R352 _HPR1S RASTB_ HPOFS R353 _HPOFS STROBE MDAT _ Q317 DATA MCK_ KRC404E PRE PPF :4.90V R317 Q331 MAIN-2 PRE 1 ON: 4.90V KRC404E R331 Q319 PRE 2 ON: 4.90V...
Page 98
• RF-A UNIT (RF-2) +10V L1221 R1204 1000U -12V 6.8k C1224 220P RF-1 R1285 R1223 R1224 R1228 36KHz 3.9K IC1221 IC1222 R1225 R1229 NJM074M J1301 TS522ID C1202 R1303 C1301 Q1201 HRIF R1201 1 MSVA C1221 R1222 C1225 KTC3770U TO MAIN 180P I C1222 I C1222...
