Specifications; General; Transmitter - Icom IC-i7410 Instruction Manual

15

SPECIFICATIONS

■ General

• Frequency coverage
Receive
0.030–60.000*
Transmit
1.800–1.999*
5.33050* , 5.34650*
3
5.37150* , 5.40350*
3
7.000–7.300*
14.000–14.350*
21.000–21.450*
28.000–29.700*
*
1 Some frequency bands are not guaranteed.
*
2 Depending on version.
• Mode
• No. of memory channels : 101CH
• Antenna impedance
• Antenna connector type : SO-239 × 2
• Usable temperature range : 0˚C to +50˚C (+32˚F to +122˚F)
• Frequency stability
• Frequency resolution
• Power supply
• Power consumption
Transmit
Max. power
Receive
Standby
Max. audio
• Dimensions
(projections not included)
• Weight (approx.)
• ACC connector
• CI-V connector
109
: (unit: MHz)
*
1 2
, 3.500–3.999* ,
2 2
, 5.36650* ,
3 3
,
3
, 10.100–10.150* ,
2 2
, 18.068–18.168* ,
2 2
, 24.890–24.990* ,
2 2
, 50.000–54.000*
2 2
*
3 Only USA version.
: USB, LSB, CW, RTTY, AM, FM
( 99 regular, 2 scan edges)
: 50 ø
( at Antenna Tuner OFF)
: Less than ±0.5 ppm 5 min. after
power ON.
(0˚C to +50˚C; +32˚F
to +122˚F)
: 1 Hz
: 13.8 V DC ±15%
(negative ground)
: 23.0 A
: 2.2 A
: 3.0 A
: 315(W) × 116(H) × 343(D) mm
12.4(W) × 4.57(H) × 13.5(D) in
: 10.2 kg; 22.4 lb
: 13-pin
: 2-conductor 3.5 (d) mm (

■ Transmitter

• Output power
SSB/CW/RTTY/FM
AM
(at 13.8 V DC/+25˚C)
• Modulation system
SSB
AM
FM
• Spurious emission
HF bands
50 MHz band
• Carrier suppression
• Unwanted sideband
suppression
• ∂TX variable range
• Microphone connector
• ELEC-KEY connector
• KEY connector
• SEND connector
• ALC connector
")
1 ⁄
8
(continuously adjustable)
: 2 to 100 W
: 2 to 27 W*
(*Carrier power)
: Digital PSN modulation
: Digital Low power modulation
: Digital Phase modulation
: Less than –50 dB
: Less than –63 dB
: More than 40 dB
: More than 55 dB
: ±9.999 kHz
: 8-pin connector
: 3-conductor 6.35(d) mm (
: 3-conductor 6.35(d) mm (
: Phono jack
(RCA)
: Phono jack
(RCA)
(600 ø)
")
1 ⁄
4
")
1 ⁄
4
