4
RECEIVE AND TRANSMIT
D Keyer set mode (continued)
7.

Paddle Polarity

Set the paddle polarity.
• Normal or reverse polarity can be selected.
8.

Keyer Type

Select the keyer type for the [ELEC-KEY] connector
on the front panel.
• Straight key, BUG-KEY or ELEC-KEY can be se-
lected.
9. MIC Up/Down Keyer
Set the microphone [UP]/[DN] switches to be used
as a key. (The microphone [UP]/[DN] switches do not
work as a 'squeeze key.')
• ON : The [UP]/[DN] switches can be used as a key
for CW.
• OFF : The [UP]/[DN] switches cannot be used as a
key for CW.
NOTE: When "ON" is selected, the frequency and
memory channels cannot be changed using the
[UP]/[DN] switches.
43
(Default: NORMAL)
(Default: ELEC-KEY)
(Default: OFF)
