D Command table

Cmd. Sub cmd. Data
00 see p. 106 Send operating frequency for transceive
01 see p. 106 Send operating mode for transceive
02 see p. 106 Read band edge frequencies
03 see p. 106 Read operating frequency
04 see p. 106 Read operating mode
05 see p. 106 Send operating frequency
06 see p. 106 Send operating mode
07 Select VFO mode
00 Select VFO A
01 Select VFO B
A0 Equalize VFO A and VFO B
B0 Exchange VFO A and VFO B
08 Select Memory mode
0001 to Select memory channel
0101 ( 0001=M-CH01 to 0099=M-CH99,
0100=P1, 0101=P2)
09 Memory write
0A Memory copy to VFO
0B Memory clear
0E 00 Scan stop
01 Programmed/memory scan start
02 Programmed scan start
03 ∂F scan start
12 Fine programmed scan start
13 Fine ∂F scan start
22 Memory scan start
23 Select memory scan start
A1 Set ∂F scan span ±5 kHz
A2 Set ∂F scan span ±10 kHz
A3 Set ∂F scan span ±20 kHz
A4 Set ∂F scan span ±50 kHz
A5 Set ∂F scan span ±100 kHz
A6 Set ∂F scan span ±500 kHz
A7 Set ∂F scan span ±1 MHz
B0 Set as non-select channel
B1 Set as select channel
D0 Set scan resume OFF
D3 Set scan resume ON
0F Read Split function
(00=OFF, 01=ON)
00 Set the Split function OFF
01 Set the Split function ON
10 00 Send/read the tuning step 10 Hz (1 Hz)
01 Send/read the tuning step 100 Hz
02 Send/read the tuning step 1 kHz
03 Send/read the tuning step 5 kHz
04 Send/read the tuning step 9 kHz
05 Send/read the tuning step 10 kHz
06 Send/read the tuning step 12.5 kHz
07 Send/read the tuning step 20 kHz
08 Send/read the tuning step 25 kHz
11 00 Send/read attenuator OFF
20 Send/read 20 dB attenuator
12 00 Send/read ANT1 selection
01 Send/read ANT2 selection
13 00 Announce operating frequency, operating
mode and S-meter level with voice synthe-
sizer
01 Announce operating frequency and S-meter
level with voice synthesizer
02 Announce operating mode with voice syn-
thesizer
Description Cmd. Sub cmd.
CONTROL COMMAND
Data
14 01 0000 to Send/read [AF] position
0255 (0000=max. CCW, 0255=max. CW)
02 0000 to Send/read [RF] position
0255 (0000=max. CCW, 0255=11 o'clock)
03 0000 to Send/read [SQL] position
0255 (0000=11 o'clock, 0255=max. CW)
06 0000 to Send/read [NR] position
0255 (0000=max. CCW, 0255=max. CW)
07 0000 to Send/read inner [TWIN PBT] position
0255 ( 0000=max. CCW, 0128=center,
0255=max. CW)
08 0000 to Send/read outer [TWIN PBT] position
0255 ( 0000=max. CCW, 0128=center,
0255=max. CW)
09 0000 to Send/read [CW PITCH] position
0255 ( 0000=max. CCW (300 Hz), 0128=center
(600 Hz), 0255=max. CW (900 Hz))
0A 0000 to Send/read [RF PWR] position
0255 (0000=max. CCW to 0255=max. CW)
0B 0000 to Send/read [MIC] position
0255 (0000=max. CCW to 0255=max. CW)
0C 0000 to Send/read [KEY SPEED] position
0255 (0000=max. CCW to 0255=max. CW)
0D 0000 to Send/read [NOTCH] position
0255 ( 0000=max. CCW, 0128=center,
0255=max. CW)
0E 0000 to Send/read [COMP] position
0255 (0000=max. CCW to 0255=max. CW)
0F 0000 to Send/read [BK-IN DELAY] position
0255 (0000=max. CCW to 0255=max. CW)
12 0000 to Send/read [NB] position
0255 (0000=max. CCW to 0255=max. CW)
15 0000 to Send/read [MONI GAIN] position
0255 (0000=max. CCW to 0255=max. CW)
16 0000 to Send/read VOX gain
0255 (0000=0% to 0255=100%)
17 0000 to Send/read Anti VOX gain
0255 (0000=0% to 0255=100%)
18 0000 to Send/read CONTRAST level
0255 (0000=0% to 0255=100%)
19 0000 to Send/read BRIGHT level
0255 (0000=0% to 0255=100%)
15 01 00 Read squelch state (squelch close)
01 Read squelch state (squelch open)
02 0000 to Read S-meter level
0255 (0000=S0, 0120=S9, 0240=S9+60 dB)
11 0000 to Read RF power meter
0255 (0000=0%, 0141=50%, 0215=100%)
12 0000 to Read SWR meter
0255 ( 0000=SWR1.0, 0041=SWR1.5,
0081=SWR2.0, 0120=SWR3.0)
13 0000 to Read ALC meter
0255 (0000=Min., 0120=Max.)
14 0000 to Read COMP meter
0255 (0000=0 dB, 0120=15 dB, 0240=30 dB)
16 02 00 Send/read Preamp OFF
01 Send/read Preamp 1 ON
02 Send/read Preamp 2 ON
12 01 Send/read AGC FAST
02 Send/read AGC MID
03 Send/read AGC SLOW
22 00 Send/read Noise Blanker OFF
01 Send/read Noise Blanker ON
40 00 Send/read Noise Reduction OFF
01 Send/read Noise Reduction ON
41 00 Send/read Auto Notch function OFF
01 Send/read Auto Notch function ON
