Table 1-3 describes the light emitting diode (LED) behavior on the Summit.
Table 1-3: Summit LEDs
LED Color
Power Green
Yellow
MGMT Green flashing
Slow
Fast
Yellow
10/100Mbps Port Status LEDs
Green
Yellow
Green flashing
Off
Gigabit Ethernet Port Status LEDs
Packet Yellow
Off
Status Green on
Green flashing
Off
1-16
Indicates
The Summit is powered up.
The Summit is indicating a power, overheat, or fan failure.
The Summit is operating normally.
Power On Self Test (POST) in progress, or software download
in progress.
The Summit has failed its POST.
Link is present; port is enabled.
Frames are being transmitted/received on this port.
Link is present; port is disabled.
Link is not present.
Frames are being transmitted/received on this port.
No activity on this port.
Link is present; port is enabled;
full-duplex operation.
Link is present; port is disabled.
Link is not present.
