V LAN (VLAN )
IRTUAL S S
P P
REDEFINED ROTOCOL
The following protocol filters are predefined on the Summit:
• IP
• IPX
• NetBIOS
• DECNet
• IPX_8022
• IPX_SNAP
• AppleTalk
D P F
EFINING ROTOCOL
If necessary, you can define a customized protocol filter based on EtherType, LLC,
and/or SNAP. Up to six protocols may be part of a protocol filter. To define a protocol
filter, do the following:
• Create a protocol using the following command:
create protocol <protocol_name>
For example:
create protocol fred
The protocol name can have a maximum of 31 characters.
• Configure the protocol using the following command:
config protocol <protocol_name> add <protocol_type> <hex_value>
Supported protocol types include:
— — EtherType
etype
The values for
maintained by the IEEE. This list can be found at the following URL:
http://standards.ieee.org/regauth/ethertype/index.html
— — LLC SAP
llc
The values for
concatenating a two-digit LLC Destination SAP (DSAP) and a two-digit LLC
Source SAP (SSAP). The list of LLC SAPs can be found at the following URL:
http://stdsbbs.ieee.org/pub/general/LLC_list.txt
5-12
F
ILTERS
ILTERS
are four-digit hexadecimal numbers taken from a list
etype
are four-digit hexadecimal numbers that are created by
llc
