Port-Mirroring Configuration Commands; Port-Mirroring Commands; Port-Mirroring Example - Extreme Networks Summit1 Installation And User Manual

P -M
ORT
Port-mirroring commands are described in
Table 4-7: Port-Mirroring Configuration Commands
Command
enable mirroring port <port>
config mirroring add [mac <mac_address>
| vlan <name> | port <port> | vlan
<name> port <port>]
config mirroring delete [mac
<mac_address> | vlan <name> | port
<port> | vlan <name> port <port> | all}
disable mirroring
show mirroring
P -M
ORT
The following example selects port 3 as the mirror port, and sends all traffic coming
into or out of the switch on port 1 to the mirror port:
enable mirroring port 3
config mirroring add port 1
The following example sends all traffic coming into or out of the switch on port 1 and
the VLAN default to the mirror port:
config mirroring add port 1 vlan default
S S I
UMMIT WITCH NSTALLATION AND
C
IRRORING OMMANDS
E
IRRORING XAMPLE
U G
SER UIDE
Table 4-7.
Description
Dedicates a port on the switch to be the mirror port.
Adds a single mirroring filter definition. Up to eight
mirroring definitions can be added. You can mirror
traffic from a MAC address, a VLAN, a physical
port, or a specific VLAN/port combination.
Deletes a particular mirroring filter definition, or all
mirroring filter definitions.
Disables port-mirroring.
Displays the port-mirroring configuration.
P -M
ORT IRRORING
4-9
