The Summit Virtual Chassis is an ultra-high performance, low-cost external backplane
that connects up to eight stacked or distributed Summit switches into one cohesive
system.
Features of the Summit Virtual Chassis include the following:
• Increased port density
• Policy-based Quality of Service (QoS)
• Load-sharing links
• Extensive fault-tolerant capabilities
— Redundant power supplies
— Hot-swappable switches
• How-swappable virtual chassis
— Environmental sensors
The Summit Virtual Chassis has eight SummitLink ports. A SummitLink port is a
proprietary backplane channel used to connect Summit switches to the Summit Virtual
Chassis.
For detailed information about the Summit Virtual Chassis, refer to the Summit
Virtual Chassis Design and Installation Guide .
S S P
UMMIT WITCH
Table 4-8 describes the Summit switch ports that can be used to connect to one, two, or
four Summit Virtual Chassis units.
Table 4-8: Summit Ports to Use to Connect to the Summit Virtual Chassis
One Virtual Chassis
Summit1 Any of ports 1 - 8
Summit2 Port 17 or Port 18
Summit3 Port 25
4-10
C
HASSIS
C
ORT ONNECTIONS
Two Virtual Chassis
Ports 2 and 3, or
Ports 4 and 5, or
Ports 6 and 7
Ports 17 and 18
Four Virtual Chassis
Ports 4, 5, 6, and 7
S S I
UMMIT WITCH
U G
NSTALLATION AND SER UIDE
