Table 4-5: Port Combinations for the Summit4 and Summit4/FX
Load-Sharing
Group
4-port groups
2-port groups
Table 4-6: Port Combinations for the Summit48
Load-Sharing
Group
4-port groups
2-port groups
Load-Sharing
Group
4-port groups
2-port groups
Load-Sharing
Group
4-port groups
2-port groups
To define a load-sharing group, you assign a group of ports to a single, logical port
number. To enable or disable a load-sharing group, use the following commands:
enable sharing <master_port> grouping <portlist>
disable sharing <master_port>
The following example defines a load-sharing group that contains ports 9 through 12,
and uses the first port in the group as the master logical port 9:
enable sharing 9 grouping 9-12
In this example, logical port 9 represents physical ports 9 through 12.
