Table 4-8: Summit Ports to Use to Connect to the Summit Virtual Chassis (continued)
Summit4
Summit4/FX
Summit48
E
XTREME
The Extreme Discovery Protocol (EDP) is used to locate neighbor Extreme Networks
switches connected to the Summit Virtual Chassis. When running on a normal switch
port, EDP is used to by the Summit switches to exchange topology information with
each other. Information communicated using EDP includes the following:
• Switch MAC address (switch ID)
• Switch software version information
• Switch IP address
• Switch VLAN-IP information
• Switch port number
• Summit Virtual Chassis identifier and port number
• Listing of all virtual chassis identifiers
EDP cannot be disabled on ports that are connected to a Summit Virtual
Chassis.
When a Gigabit Ethernet port is configured to be connected to a SummitLink port on a
Summit Virtual Chassis, the Activity LED on the Summit flashes once per second, even
when no traffic is present on the network. The flashing Activity LED indicates that EDP
is running successfully between all of the Summit switches connected to the Summit
Virtual Chassis.
S S I
UMMIT WITCH NSTALLATION AND
One Virtual Chassis
Any of ports 17 - 22
Any of ports 17 - 22
Port 49 or Port 50
D P
ISCOVERY ROTOCOL
U G
SER UIDE
Two Virtual Chassis
Ports 17 and 18, or
Ports 19 and 20, or
Ports 21 and 22
Ports 17 and 18, or
Ports 19 and 20, or
Ports 21 and 22
Ports 49 and 50
S V
UMMIT IRTUAL
Four Virtual Chassis
Ports 19, 20, 21, and 22
Ports 19, 20, 21, and 22
C
HASSIS
4-11
