When deciding where to install the switch, ensure that:
• The switch is accessible and cables can be connected easily.
• Water or moisture cannot enter the case of the unit.
• Air-flow around the unit and through the vents in the side of the case is not
restricted. You should provide a minimum of 25mm (1-inch) clearance.
• No objects are placed on top of the unit.
• Units are not stacked more than four high if the switch is free-standing.
M
T
EDIA
YPES AND
The connectors, media types, and maximum distances are described in
Table 2-1: Media Types and Distances
Standard
Media Type
1000BASE-SX
50/125um Multimode Fiber
50/125um Multimode Fiber
62.5/125um Multimode Fiber
62.5/125um Multimode Fiber
1000BASE-LX
50/125um Multimode Fiber
50/125um Multimode Fiber
62.5/125um Multimode Fiber
10u Single-mode Fiber
1000BASE-LX10*
10u Single-mode Fiber
100BASE-FX
50/125um Multimode Fiber
(half-duplex operation
50/125um Multimode Fiber
(full-duplex operation)
62.5/125um Multimode Fiber
(half-duplex operation)
52.5/125um Multimode Fiber
(full-duplex operation)
100BASE-TX
Category 5 UTP Cable (100Mbps)
10BASE-T
Category 3 UTP Cable (10Mbps)
*E
N
XTREME
ETWORKS PROPRIETARY
5,000 M
.
OF
ETERS
2-2
D
ISTANCES
. C
1000BASE-LX
AN BE CONNECTED TO
Table 2-1.
Mhz/Km
Maximum
Rating
Distance
400
500 Meters
500
550 Meters
160
220 Meters
200
275 Meters
400
550 Meters
500
550 Meters
500
550 Meters
5,000 Meters
10,000 Meters
400 Meters
2000 Meters
400 Meters
2000 Meters
100 Meters
100 Meters
-
ON SINGLE
MODE FIBER USING A MAXIMUM DISTANCE
S
UMMIT
S
I
U
WITCH
NSTALLATION AND
SER
G
UIDE
