Table 3-6: Supported MIBs (continued)
Description
OSPF2 MIB
RMON II Probe Configuration
802.3 MAU MIB
The IEEE Bridge MIB dot1dTpPortEntry PortInDiscards and dot1dBasePortEntry
counters are not incremented.
C
ONFIGURING
The following SNMP parameters can be configured on the switch:
• Authorized trap receivers — An authorized trap receiver can be one or more
network management stations on your network. The switch sends SNMP traps to all
trap receivers. You can have a maximum of six trap receivers configured for each
Summit. Entries in this list can be created, modified, and deleted using the RMON2
trapDestTable MIB variable, as described in RFC 2021.
• Authorized managers — An authorized manager can be either a single network
management station, or a range of addresses (for example, a complete subnet)
specified by a prefix and a mask. The Summit can have a maximum of thirty-two
authorized managers.
• Community strings — The community strings allow a simple method of
authentication between the switch and the remote Network Manager. There are two
types of community strings on the Summit. Read community strings provide
read-only access to the switch. The default read community string is public.
Read-write community strings provide read and write access to the switch. The
default read-write community string is private. A total of eight community strings
can be configured on the switch. The community string for all authorized trap
receivers must be configured on the switch for the trap receiver to receive
switch-generated traps.
• System contact (optional) — The system contact is a text field that enables you to
enter the name of the person(s) responsible for managing the switch.
• System name — The system name is the name that you have assigned to this switch.
The default name is the model name of the Summit (for example, Summit1).
• System location (optional) — Using the system location field, you can enter an
optional location for this switch.
S S I
UMMIT WITCH NSTALLATION AND
RFC Number
1850
2021
2239
SNMP S
ETTINGS
U G
SER UIDE
U SNMP
SING
3-19
