Configuring Rip; Rip Configuration Commands - Extreme Networks Summit1 Installation And User Manual

R P
OUTING ROTOCOLS
C
ONFIGURING
Table 10-1 describes the commands used to configure RIP.
Table 10-1: RIP Configuration Commands
Command
enable rip
enable rip aggregation
enable rip exportstatic
enable rip poisonreverse
enable rip splithorizon
enable rip triggerupdate
10-8
RIP
Description
Enables RIP. The default setting is disabled.
Enables RIP aggregation of subnet information
an interface configured to sent RIP v2 or RIP
v2-compatible traffic. The switch summarizes
subnet routes to the nearest class network
route. The following rules apply when using
RIP aggregation:
Subnet routes are aggregated to the
nearest class network route when crossing
a class boundary.
Within a class boundary, no routes are
aggregated.
If aggregation is enabled, the behavior is
the same as in RIP v1.
If aggregation is disabled, subnet routes
are never aggregated, even when crossing
a class boundary.
The default setting is enabled.
Enables the advertisement of static routes
using RIP. The default setting is enabled.
Enables the split horizon with poison-reverse
algorithm for RIP. The default setting is
enabled. If you enable poison reverse and
split horizon, poison reverse takes precedence.
Enables the split horizon algorithm for RIP.
Default setting is enabled.
Enables triggered updates. Triggered update s
are a mechanism for immediately notifying a
router's neighbors when the router adds or
deletes routes, or changes the metric of a
route. The default setting is enabled.
S S I
UMMIT WITCH NSTALLATION AND
U G
SER UIDE
