R P
OUTING ROTOCOLS
Table 10-1: RIP Configuration Commands (continued)
Command
config rip updatetime {<delay>}
RIP C
ONFIGURATION
Figure 10-4 illustrates a switch that has three VLANs defined as follows:
• Finance
— Protocol-sensitive VLAN using the IP protocol
— Ports 1 and 3 have been assigned
— IP address 192.207.35.1
• Personnel
— Protocol-sensitive VLAN using the IP protocol
— Ports 2 and 4 have been assigned
— IP address 192.207.36.1
• MyCompany
— Port-based VLAN
— All ports have been assigned
10-10
Description
Changes the periodic RIP update timer. The
timer granularity is 10 seconds. The default
setting is 30 seconds.
E
XAMPLE
S S I
