O IP U R
VERVIEW OF NICAST OUTING
Once configured, the Summit responds to ARP Requests on behalf of the device as long
as the following conditions are satisfied:
• The valid IP ARP Request is received on a Summit router interface.
• The target IP address matches the IP address configured in the proxy ARP table.
• The proxy ARP table entry indicates that the switch should always answer this ARP
Request (the parameter must be applied).
always
Once all the proxy ARP conditions are met, the Summit formulates an ARP Response
using the configured MAC address in the packet.
P ARP B S
ROXY ETWEEN UBNETS
In some networks, it is desirable to configure the IP host with a wider subnet than the
actual subnet mask of the segment. Proxy ARP can be used so that the router answers
ARP Requests for devices outside of the subnet. As a result, the host communicates as if
all devices are local. In reality, communication with devices outside of the subnet are
proxied by the router.
For example, an IP host is configured with a class B address of 100.101.102.103 and a
mask of 255.255.0.0. The Summit is configured with the IP address 100.101.102.1 and a
mask of 255.255.255.0. The Summit is also configured with a proxy ARP entry of IP
address 100.101.0.0 and mask 255.255.0.0, without the parameter.
always
When the IP host tries to communicate with the host at address 100.101.45.67, the IP
hosts communicates as if the two hosts are on the same subnet, and sends out an IP
ARP Request. The Summit answers on behalf of the device at address 100.101.45.67,
using its own MAC address. All subsequent data packets from 100.101.102.103 are sent
to the switch, and the switch routes the packets to 100.101.45.67.
IP M
ULTINETTING
IP multinetting is used in many legacy IP networks when there is a need to overlap
multiple subnets into one physical segment. On the Summit, you can only assign a
single IP address to a router interface (one IP address per VLAN). To support IP
multinetting, you must assign multiple VLANs to the same physical port. The Summit
routes IP traffic from one subnet to another, all within the same physical port.
