The task frame has two sections. At the top of the task frame are the task tabs. There are
four task tabs, as follows:
• Configuration
• Statistics
• Support
• Logout
Below the task tabs are options. Options are specific to the task tab that you select.
When you select an option, the information displayed in the content frame changes.
However, when you select a new task tab, the content frame does not change until you
select a new option.
C F
ONTENT RAME
The content frame contains the main body of information in ExtremeWare Vista. For
example, if you select an option from the Configuration task tab, enter configuration
parameters in the content frame. If you select the Statistics task tab, statistics are
displayed in the content frame.
B C
ROWSER ONTROLS
Browser controls include drop-down list boxes, check boxes, and multi-select list boxes.
A multi-select list box has a scrollbar on the right side of the box. Using a multi-select
list box, you can select a single item, all items, a set of contiguous items, or multiple
non-contiguous items.
list box.
Table 13-1: Multi-Select List Box Key Definitions
Selection Type
Single item
All items
Contiguous items
13-4
Table 13-1 describes how to make selections from a multi-select
Key Sequence
Click the item using the mouse.
Click the first item, and drag to the
last item.
Click the first desired item, and
drag to the last desired item.
