Table 10-1: RIP Configuration Commands (continued)
Command
config rip add {vlan <name> | all}
config rip delete [vlan <name> | all]
config rip garbagetime {<delay>}
config rip routetimeout {<delay>}
config rip rxmode [none | v1only | v2only |
any] {vlan <name> | all}
config rip txmode [none | v1only | v1comp |
v2only] {vlan <name> | all}
S S I
UMMIT WITCH NSTALLATION AND
U G
SER UIDE
Description
Configures RIP on an IP interface. If no VLAN
is specified, then all is assumed. When an
IP interface is created, per interface RIP
configuration is disabled by default.
Disables RIP on an IP interface. When RIP is
disabled on the interface, the parameters are
not reset to their defaults.
Configures the RIP garbage time. The timer
granularity is 10 seconds. The default setting is
120 seconds.
Configures the route timeout. The timer
granularity is 10 seconds. The default setting is
180 seconds.
Changes the RIP receive mode for one or
more VLANs. Specify:
none — Drop all received RIP packets.
v1only — Accept only RIP version 1
format packets.
v2only — Accept only RIP version 2
format packets.
any — Accept both version 1 and version
2 packets.
If no VLAN is specified, the setting is applied to
all VLANs. The default setting is any.
Changes the RIP transmission mode for one or
more VLANs. Specify:
none — Do not transmit any packets on
this interface.
v1only — Transmit RIP version 1 format
packets to the broadcast address.
v1comp — Transmit version 2 format
packets to the broadcast address.
v2only — Transmit version 2 format
packets to the RIP multicast address
If no VLAN is specified, the setting is applied to
all VLANs. The default setting is v2only.
C RIP
ONFIGURING
10-9
