Page 4 Summit Switch Overview Summit Switch Models Summary of Features Summit “i” series and non-”i” series switches Summit24e2 Summit24e3 SummitPx1 Summit 200 Series Memory Requirements Port Connections Following Safety Information Chapter 4 Summit Switch Models Switch Models Extreme Networks Consolidated Hardware Guide...
Page 5 Summit48i Switch Front View GBIC Ports LEDs Summit48i Switch Rear View Power Sockets Label Reset Button Console Port Summit48si Switch Front View Mini-GBIC Ports Console Port LEDs Summit48si Switch Rear View Power Supplies Reset Button Extreme Networks Consolidated Hardware Guide...
Page 6 Reset Button Software Requirements Summit24e3 Switch Rear View Power Socket Label Summit24e3 Switch LEDs SummitPx1 Application Switch Front View GBIC Network Interface LEDs Ethernet Management Port Serial Management Console Port Serial Management Modem Port Software Requirements Extreme Networks Consolidated Hardware Guide...
Page 7 Removing the AC Power Cable Retaining Bracket from a Power Cable Removing the Switch from a Rack Part 4 Alpine Switch Chapter 6 Alpine 3800 Series Switch Overview Summary of Features Port Connections Switch Components Alpine 3808 Switch Extreme Networks Consolidated Hardware Guide...
Page 8 Chapter 8 Alpine 3800 Series Switch Power Supplies Power Supply LEDs Installing the Alpine 3808 and the Alpine 3804 AC Power Supply Verifying a Successful Installation Removing the Alpine 3808 and the Alpine 3804 AC Power Supply Supplying Power to the Alpine 3802 AC Power Supply...
Page 9 Alpine 3800 Series Switch Fan Tray Alpine 3808 Fan Tray Alpine 3804 Fan Tray Alpine 3802 Fan Tray Removing the Alpine 3808 or Alpine 3804 Fan Tray Installing the Alpine 3808 or Alpine 3804 Fan Tray Part 5 BlackDiamond Switch Chapter 12...
Page 10 BlackDiamond 6800 Series Management Switch Module MSM64i Activity MSM64i Memory MSM64i LEDs Installing MSM64i Modules Verifying the MSM64i Module Installation Removing MSM64i Modules Chapter 16 BlackDiamond 6800 Series I/O Modules Configuring I/O Modules G8Ti Module Extreme Networks Consolidated Hardware Guide...
Page 11 Part 6 Switch Operation Chapter 18 Initial Switch and Management Access Connecting Equipment to the Console Port Logging In for the First Time Part 7 Appendixes Appendix A Safety Information Important Safety Information Power Power Cable Extreme Networks Consolidated Hardware Guide Module Module...
Page 12 Fuse Connections Lithium Battery Appendix B Switch Technical Specifications Appendix C Module Technical Specifications Alpine Modules BlackDiamond Modules Common Module Specifications Index Extreme Networks Consolidated Hardware Guide...
Page 13: Preface
This preface provides an overview of this guide, describes guide conventions, and lists other publications that might be useful. NOTE To ensure proper operation of your Extreme Networks equipment, read this guide before you install any Extreme Networks equipment. Introduction...
Page 14: Conventions
Related Publications The Extreme Networks switch documentation set includes: • Extreme Networks Consolidated Hardware Guide (this guide) • ExtremeWare Software User Guide • ExtremeWare Quick Reference Guide • ExtremeWare Software Command Reference Guide •...
Page 15: About This Guide
• Archives About This Guide This guide describes how to prepare your site and how to install, maintain, and operate your Extreme Networks switch. It contains information on features that are common to all switches, as well as switch-specific features. This guide contains seven parts: •...
Page 16 I/O Modules” in Chapter 16 for details about how to remove and replace an I/O module in a BlackDiamond chassis. Common Information For items applicable to any Extreme Networks switch, make sure you read the appropriate chapter. For example, to learn how to prepare your site for installing your Extreme Networks equipment, see Chapter 2, “Site Preparation.”...
Page 17: Part 1 Common Features
Part 1 Common Features...
Page 19: Summary Of Common Switch Features
Summary of Common Switch Features This chapter describes the features that are shared in common by the Extreme Networks family of switches. The following topics are described in greater detail: • Software Images on page 19 • Full-Duplex Support on page 20 •...
Page 20: Full-Duplex Support
• BlackDiamond—Management Switch Fabric Module (MSM64i) for the BlackDiamond series switch Extreme Networks does not recommend that you use the management port to route traffic to any front panel port on the switch. The management port is designed for switch management purposes.
Page 21 General Total system budget Total optical system budget for the SX mini-GBIC is 11.5 dB. Extreme Networks recommends that 3 dB of the total budget be reserved for losses induced by cable splices/connectors and operating margin. While 8.5 dB remains available for cable induced attenuation, the 1000BASE-SX standard specifies supported distances of 275 meters over 62.5 micron multimode fiber and 550 meters over 50 micron...
Page 22: Safety Information
CAUTION Mini-GBICs can emit invisible laser radiation. Avoid direct eye exposure to beam. Mini-GBICs are class 1 laser devices, and they operate at 3.3 V. Use only Extreme Networks-certified mini-GBIC devices. If you see an amber blinking mini-GBIC port status LED after you install a mini-GBIC into the...
Page 23: Installing And Removing A Mini-Gbic
If you see an amber blinking mini-GBIC port status LED on your Summit48si, Summit24e3, or Summit 200 series switch, a BlackDiamond G16X installed in your switch or module is not approved, supported, or certified by Extreme Networks. To correct this problem, ensure that you install an Extreme Networks-certified mini-GBIC.
Page 24: Gbic Type And Hardware/Software Support
GBIC Type and Hardware/Software Support Most Extreme Networks switches support two types of GBICs: the Parallel ID GBIC and the Serial ID GBIC. The switch can identify the media type for the GBIC that is installed. Initial ExtremeWare software versions do not support Serial ID GBICs.
Page 25: Gbic Specifications
(1550 nm optical window) LX100 (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. GBIC Specifications Table 8 through Table 14 describe the specifications for each GBIC type.
Page 26 If you see one of the following on the label, you have a ZX GBIC Rev 03 module: • DVA-1203 sticker near the top of the label that covers the Extreme Networks logo • ZX GBIC (1203) text near the top of the label •...
Page 27 The Summit24e2 switch does not support the LX100 GBIC. Do not install an LX100 GBIC into the Summit24e2 switch. If you have an Alpine 3800 series switch populated with a GM-4Xi module, do one of the following: • Install a maximum of three LX100 GBICs per GM-4Xi module; the fourth GBIC slot must remain empty •...
Page 28: Long Range Gbic System Budgets
(for example, 0.25 db/km), Extreme Networks recommends that 3 dB of the total budget be reserved for losses induced by cable splices, connectors, and operating margin. Figure 2 shows the total optical system budget between long range GBICs.
Page 29: Safety Information
GBICs can emit invisible laser radiation. Avoid direct eye exposure to beam. GBICs are class 1 laser devices, and they operate at 5 V. Use only Extreme-approved devices. Remove the SC fiber-optic or the RJ-45 connector from the GBIC prior to removing the GBIC from the I/O module or the switch.
Page 30: Installing Or Replacing A Gbic
After you complete all of these described tasks, you are ready to install or replace a GBIC. Installing or Replacing a GBIC You can add and remove GBICs from your Extreme Networks switch without powering off the system. Figure 3 shows the three types of GBIC connectors.
Page 31 To insert a GBIC connector: 1 Holding the GBIC by its sides, insert the GBIC into the slot on the I/O module or the switch. 2 Slide the GBIC into the slot until you hear an audible click, indicating the GBIC is securely seated. If the GBIC has a handle, push down on the handle to secure the GBIC.
Page 32 Summary of Common Switch Features Extreme Networks Consolidated Hardware Guide...
Page 33: Part 2 Site Planning
Part 2 Site Planning...
Page 35: Chapter 2 Site Preparation
Site Preparation This chapter describes how to prepare your site for installing Extreme Networks equipment. It contains information on environmental and cabling requirements, power requirements, and building and electrical code organizations. This chapter includes these sections: • Planning Your Site on page 36 •...
Page 36: Planning Your Site
(or cabling). Step 3: Meeting Power Requirements To run your equipment safely, you must meet the specific power requirements for the Extreme Networks equipment that you plan to install. NOTE Review and follow the safety information before you install your equipment.
Page 37 • Ensure that your system is easily accessible for installation and service. See “Rack Specifications and Recommendations” on page 45 for specific recommendations. • Use appropriate AC power for your switch, as described in Table 16. Table 16: AC power requirements...
Page 38 • Ensure that all system environmental requirements are met, such as ambient temperature and humidity. NOTE Extreme Networks recommends that you consult an electrical contractor for commercial building and wiring specifications. Requirements 20 A service receptacle, NEMA L6-20 (locking) for BlackDiamond 110 VAC power supplies.
Page 39 • The Summit family of switches require 3 inches (7.62 cm) on both the left and right sides of the switch (5 inches (12.7 cm) recommended) for proper airflow. • The Alpine 3800 series chassis require 3 inches (7.62 cm) on both the left and right sides of the switch (5 inches (12.7 cm) recommended) for proper airflow.
Page 40 The airflow of the Alpine 3808 moves through the power supplies and is independent of the airflow through the chassis as shown in Figure 4. For example, if the power supply fans fail, the airflow through the module area of the chassis will not cool down the power supplies.
Page 41 Figure 5: Airflow through the Alpine 3804 chassis Airflow through chassis Figure 6: Airflow through the Alpine 3802 chassis Airflow through chassis Extreme Networks Consolidated Hardware Guide Meeting Site Requirements Airflow through chassis 38_air4 Airflow through chassis 3802air...
Page 42 • Airflow for cooling power supplies moves front to back as you face the chassis. • Airflow for cooling modules moves left to right as you face the chassis. Figure 7: Airflow through the BlackDiamond 6816 chassis Airflow through chassis Airflow through power supplies BD_032 Extreme Networks Consolidated Hardware Guide...
Page 43 Figure 8: Airflow through the BlackDiamond 6808 chassis Airflow through chassis POWER Airflow through power supplies Extreme Networks Consolidated Hardware Guide 50015 50015 POWER DC OUT DC OUT AC IN AC IN 50021 50021 Meeting Site Requirements BD_027...
Page 44 • Use electrostatically safe equipment and the ESD straps that are provided with your equipment. All Alpine and BlackDiamond switches come with ESD wrist strap connectors and wrist straps as shown in Figure 10. Airflow from fan tray 6804air Extreme Networks Consolidated Hardware Guide...
Page 45: Rack Specifications And Recommendations
Figure 10: Ensure that you use an ESD wrist strap when handling switch components ESD strap connector Connected wrist strap Rack Specifications and Recommendations Racks should conform to conventional standards. In the United States, use EIA Standard RS-310C: Racks, Panels, and Associated Equipment. In countries other than the United States, use IEC Standard 297.
Page 46 Space Requirements for the Rack Provide enough space in front of and behind the switch so that you can service it easily. Allow a minimum of 48 inches (122 cm) in front of the rack and 24 inches (61 cm) behind the rack. When using a relay rack, provide a minimum of 24 inches (61 cm) of space behind the mounted equipment.
Page 47: Evaluating And Meeting Cable Requirements
• Radio Frequency Interference Cabling Standards We recommend using the BICSI (Building Industry Consulting Service International) RCDD (Registered Communications Distribution Designer), which is globally recognized as a standard in site planning and cabling. For information, go to http://www.bicsi.org Extreme Networks Consolidated Hardware Guide...
Page 48: Cable Labeling And Record Keeping
• Assign a unique block of sequential numbers to the group of cables that run between each pair of wiring closets. • Assign a unique identification number to each distribution rack. • Identify all wiring closets by labeling the front panel of your Extreme Networks equipment and other hardware. • Keep accurate and current cable identification records.
Page 49 Unshielded twisted pair (UTP) cable can build up ESD charges when being pulled into a new installation. Before installing category 5 UTP cables, discharge ESD from the cable by plugging it into a port on a switch or any network device that is not powered on. Figure 12: Properly installed and bundled cable...
Page 50 62.5/125 µm multimode fiber 62.5/125 µm multimode fiber Minimum 2 in. (5.08cm) radius in 90˚ bend 90˚ Optical fiber cable Mhz•Km Maximum Distance Rating (Meters) – 5,000 – 10,000 – 70,000 2000 2000 2000 2000 SPG_002 Extreme Networks Consolidated Hardware Guide...
Page 51: Rj-45 Connector Jackets
Category 5 and higher UTP cable 10BASE-T Category 3 and higher UTP cable Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use 10/125 µm single-mode fiber can use a maximum distance of 10,000 meters. RJ-45 Connector Jackets Use RJ-45 cable with connector jackets that are flush with the connector or that have connectors with a no-snag feature.
Page 52: Making Network Interface Cable Connections
In areas or applications where these situations cannot be avoided, use fiber optic cabling or shielded twisted pair cabling (STP). NOTE Because harmonics can appear on the neutral line of a typical three-phase power circuit, Extreme Networks recommends using a harmonics meter in new installations. Making Network Interface Cable Connections Use the appropriate type of cable to connect the ports of your switch to another switch or router.
Page 53: Power Supply Requirements
For more information about the power specifications of the Extreme Networks family of switches, see Appendix B, “Switch Technical Specifications” on page 303. Power Supply Requirements Adhere to the following requirements in order to operate your Extreme Networks equipment safely: •...
Page 54: Uninterruptable Power Supply Requirements
An uninterruptible power supply (UPS) is a device that sits between a power supply (such as a wall outlet) and a device (such as a switch) to prevent outages, sags, surges, and bad harmonics from adversely affecting the performance of the device.
Page 55: Applicable Industry Standards
UPS Transition Time Transition time is the time that is necessary for the UPS to transfer from utility power to full-load battery power. For Extreme Networks products, a transition time of less than 20 milliseconds is required for optimum performance.
Page 56 Site Preparation Extreme Networks Consolidated Hardware Guide...
Page 57: Part 3 Summit Switch
Part 3 Summit Switch...
Page 59: Chapter 3 Summit Switch Overview
The following models comprise the Summit family of switches: • Summit1i • Summit5i • Summit7i • Summit48i • Suumit48si • Summit4 • Summit4/FX • Summit24e2 • Summit24e3 • SummitPx1 • Summit 200-24 • Summit 200-48 Extreme Networks Consolidated Hardware Guide...
Page 60: Summary Of Features
This section describes the features of the Summit family of switches. If the information in the release notes differs from the information in this guide, follow the release notes. For more information about configuring the switch, refer to the ExtremeWare Software User Guide and The ExtremeWare Command Reference Guide.
Page 61: Summit24E2
Summary of Features • Remote Monitoring (RMON) • Adjustable fan speed based on the temperature of the switch (Summit48si only) Summit24e2 • VLANs, including support for IEEE 802.1Q and IEEE 802.1p • STP (IEEE 802.1D) • Broadcast and Multicast storm filtering •...
Page 62: Summit 200 Series
• Load sharing on multiple ports • RADIUS client and per-command authentication support • TACACS+ support • Network Login • CLI connection • Telnet CLI connection • SSH2 connection • SNMP • Remote Monitoring (RMON) • Traffic mirroring for ports Extreme Networks Consolidated Hardware Guide...
Page 63: Memory Requirements
Memory Requirements Your “i” series Summit switch must have 128MB of DRAM in order to support the features in ExtremeWare version 6.0 or later. To determine the memory size in your switch, use the following command: show memory For Summit switches running ExtremeWare 4.0 or later, the switch indicates the total DRAM size in megabytes as part of the output.
Page 64: Following Safety Information
Following Safety Information WARNING! Read the safety information in Appendix A thoroughly before installing your Extreme Networks switch. Failure to follow this safety information can lead to personal injury or damage to the equipment. • All service to components of a Summit series switch should be performed by trained service personnel only.
Page 65: Switch Models
Summit Switch Models This chapter describes: • Front and rear views of the Summit switch models • LEDs on the Summit switch models Switch Models The following models comprise the Summit family of switches: • Summit1i on page 66 • Summit5i on page 69 •...
Page 66: Summit1I Switch Front View
Summit Switch Models Summit1i Switch Front View As shown in Figure 15 and Figure 16, the Summit1i switch is 2U in height and is available in two port configurations: • Six autosensing 100BASE-TX/1000BASE-T ports with RJ-45 connectors and two 1000BASE-X ports with SC connectors •...
Page 67: Leds
(1550 nm optical window) LX100 (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. NOTE For more information about the supported GBIC types, see “GBIC Specifications” on page 25.
Page 68: Summit1I Switch Rear View
• Model number—Shows the model number assigned to this device • Part number—Shows the part number assigned to this device • Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device...
Page 69: Summit5I Switch Front View
Summit5i Switch Front View As shown in Figure 18, Figure 19, and Figure 20, the Summit5i switch is 2U in height and is available in three port configurations: • 12 autosensing 100BASE-TX/1000BASE-T ports with RJ-45 connectors and 4 1000BASE-X ports with SC connectors •...
Page 70: Gbic Ports
Figure 20: Front view of the Summit5i switch with 1000BASE-LX ports ort status LEDs GBIC Ports All three Summit5i switch models provide four unpopulated GBIC ports with SC connectors. You can use the following GBICs in the Summit5i switch: • 1000BASE-SX •...
Page 71: Leds
Table 22: GBIC types and maximum distances (continued) Standard LX100 (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. NOTE For more information about the supported GBIC types, see “GBIC Specifications” on page 25.
Page 72: Label
NOTE Summit5i switch power supplies must be serviced by personnel trained by Extreme Networks, only. Label The label on the rear of the Summit5i switch displays important information about your switch. Write down your switch information before you install the switch: •...
Page 73: Summit7I Switch Front View
Summit7i Switch Front View As shown in Figure 22 and Figure 23, the Summit7i switch is 4U in height and is available in two port configurations: • 28 autosensing 100BASE-TX/1000BASE-T ports with RJ-45 connectors and 4 1000BASE-X ports with SC connectors •...
Page 74: Gbic Ports
29 30 31 32 Port status 1000BASE-SX ports LEDs GBIC Ports Both Summit7i switch models provide four unpopulated GBIC ports with SC connectors. You can use the following GBICs in the Summit7i switch: • 1000BASE-SX • 1000BASE-LX • 1000BASE-LX70 • ZX GBIC •...
Page 75: Leds
(1550 nm optical window) LX100 (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. NOTE For more information about the supported GBIC types, see “GBIC Specifications” on page 25.
Page 76: Modem Port
Summit7i switch. If one of the power sources or power supplies fails, the second power supply provides all power needs which ensures uninterrupted network operation. NOTE Summit7i switch power supplies must only be serviced by personnel trained by Extreme Networks. Extreme Networks Consolidated Hardware Guide...
Page 77: Label
• Model number—Shows the model number assigned to this device • Part number—Shows the part number assigned to this device • Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device.
Page 78: Leds
10/125 µm single-mode fiber (1550 nm optical window) Category 5 UTP cable *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. NOTE For more information about the supported GBIC types, see “GBIC Specifications” on page 25.
Page 79: Summit48I Switch Rear View
• An SNMP trap to your network management station NOTE Summit48i switch power supplies must only be serviced by personnel trained by Extreme Networks. Label The label on the rear of the Summit48i switch displays important information about your switch. Write down the following information before you install the switch: •...
Page 80: Summit48Si Switch Front View
Mini-GBIC ports 48si_dtl Mini-GBIC Ports The Summit48si switch has two unpopulated Extreme mini-GBIC ports using LC connectors. You can use the 1000BASE-SX mini-GBIC, the 1000BASE-LX mini-GBIC, or the ZX mini-GBIC in the Summit48si switch. Use only Extreme Networks-certified mini-GBICs, available from Extreme Networks, into the mini-GBIC port in the switch.
Page 81: Console Port
The Summit48si switch has the following LEDs: • Management • Port status For information about the LEDs and their activity on the Summit48si switch, see “Summit1i, Summit5i, Summit7i, Summit48i, and Summit48si Switch LEDs” on page 84. Summit48si Switch Rear View Figure 29 shows the rear view for the Summit48si switch.
Page 82: Reset Button
• An SNMP trap to your network management software Reset Button Use the reset button to cycle the switch down and bring the switch back up without powering off the switch. Your saved switch configuration information is not lost; unsaved switch configurations are lost.
Page 83: Summit48Si Switch Bottom View
• Model number—Shows the model number assigned to this device • Part number—Shows the part number assigned to this device • Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device...
Page 84: Summit1I, Summit5I, Summit7I, Summit48I, And Summit48Si Switch Leds
Summit1i, Summit5i, Summit7i, Summit48i, and Summit48si Switch LEDs Table 26 describes the LED activity on the Summit1i, Summit5i, Summit7i, Summit48i, and Summit48si switches. Table 26: Switch LED activity for the Summit1i, Summit5i, Summit7i, Summit48i, and Summit48si Color Unit Status LEDs PSU A, PSU B...
Page 85: Summit4 Switch Front View
• Management • Port status • Gigabit Ethernet port status For information about the LEDs and their activity on the Summit4 switch, see “Switch LED activity for the Summit4 and Summit4/FX” on page 88. Extreme Networks Consolidated Hardware Guide Port status...
Page 86: Summit4/Fx Switch Front View
Summit Switch Models Summit4/FX Switch Front View The Summit4/FX switch is 2U in height and has 16 100BASE-FX ports and 6 Gigabit Ethernet ports with standard SC connectors. The Gigabit Ethernet ports support 1000BASE-SX over multimode fiber-optic cable. Figure 33 shows the front view of the Summit4/FX switch.
Page 87: Summit4 Switch Rear View
• Model number—Shows the model number assigned to this device • Part number—Shows the part number assigned to this device • Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device Console Port Use the console port (9-pin, “D”...
Page 88: Reset Button
Summit Switch Models Reset Button Use the reset button to cycle the switch down and bring the switch back up without powering off the switch. Your saved switch configuration information is not lost; unsaved switch configurations are lost. Use a non-conductive tool to push the reset button.
Page 89: Summit24E2 Switch Front View
Use the console port (9-pin, “D” type connector) to attach a terminal and access the CLI via a serial connection. Use the console port for local management. GBIC Ports The Summit24e2 switch provides two Gigabit Ethernet ports. All of the Gigabit Ethernet ports use SC connectors. You can use the following GBICs in the Summit24e2 switch: • 1000BASE-SX •...
Page 90: Leds
LX70 10/125 µm single-mode fiber (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. NOTE For more information about the supported GBIC types, see “GBIC Specifications” on page 25.
Page 91: Summit24E2 Switch Leds
Color Green Green blinking NOTE For more information about configuring and using the Summit24e2 switch, see the Summit24e2 Installation and User Guide. Summit24e3 Switch Front View The Summit24e3 switch is 1U in height and has 24 autosensing and auto-polarity 10BASE-T/100BASE-TX ports using RJ-45 connectors and 2 mini-GBIC ports using LC connectors.
Page 92: Mini-Gbic Ports
Reset button SH_24e3_dtl Mini-GBIC Ports The Summit24e3 switch has two unpopulated Extreme mini-GBIC ports using LC connectors. You can use the 1000BASE-SX mini-GBIC, the 1000BASE-LX mini-GBIC, or the ZX mini-GBIC in the Summit24e3 switch. Use only Extreme Networks-certified mini-GBICs, available from Extreme Networks, into the mini-GBIC port in the switch.
Page 93: Reset Button
Summit24e3 Switch Rear View Reset Button Use the reset button to cycle the switch down and bring the switch back up without powering off the switch. Your saved switch configuration information is not lost; unsaved switch configurations are lost. Use a non-conductive tool to push the reset button.
Page 94: Summit24E3 Switch Leds
Link is present; port is enabled for full-duplex operation. Green blinking Link is present; port is disabled. Link is not present. NOTE For more information about configuring and using the Summit24e3 switch, see the Summit24e3 Installation and User Guide. Extreme Networks Consolidated Hardware Guide...
Page 95: Summitpx1 Application Switch Front View
Figure 40: Front view of the SummitPx1 application switch Unit status LEDs GBIC Network Interface The Network Interface port is a GBIC used to connect the application switch to your local network. LEDs The SummitPx1 application switch has the following LEDs: • Link •...
Page 96: Serial Management Modem Port
• Model number—Shows the model number assigned to this device • Part number—Shows the part number assigned to this device • Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device...
Page 97: Summitpx1 Application Switch Leds
The Summit 200-24 is 1U in height and has 24 autosensing 10BASE-T/100BASE-TX ports using RJ-45 connectors. It also provides two 10/100/1000BASE-T Gigabit Ethernet uplink ports using RJ-45 connectors and two optical ports that also allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX mini-GBICs using LC optical fiber connectors.
Page 98: Console Port
10/100Mbps Ethernet. The switch also has four Gigabit Ethernet uplink ports. These ports are labeled 25 and 26 on the front panel of the switch. Two of the ports are 10/100/1000BASE-T ports using RJ-45 connectors. The other two ports are unpopulated receptacles for mini-SFP GBICs, using optical fibers with LC connectors.
Page 99: Summit 200-24 Switch Rear View
• Model number—Shows the model number assigned to this device • Part number—Shows the part number assigned to this device • Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device NOTE The Summit 200-24 switch certification and safety label is located on the bottom of the switch.
Page 100 The switch acting as the stack master will be assigned the number 0, which is the default. NOTE For more information about configuring and using the Summit200-24 switch, see the Summit 200 Series Switch Installation and User Guide. Extreme Networks Consolidated Hardware Guide...
Page 101: Summit 200-48 Switch Front View
10/100Mbps Ethernet. The switch also has four Gigabit Ethernet uplink ports. These ports are labeled 49 and 50 on the front panel of the switch. Two of the ports are 10/100/1000BASE-T ports using RJ-45 connectors. The other two ports are unpopulated receptacles for mini-SFP GBICs, using optical fibers with LC connectors.
Page 102: Leds
Summit Switch Models NOTE When configuring the Summit 200-48 switch, all ports specified as mirrored ports and mirroring port, or ACL ingress ports and egress port, must belong to the same port group. Port group 1 consists of ports 1 through 24 and port 49; port group 2 consists of ports 25 through 48 and port 50.
Page 103: Summit 200-48 Switch Leds
• Serial number—Refer to the serial number when you contact Extreme Networks technical support • MAC address—Shows the unique Ethernet MAC address assigned to this device NOTE The Summit 200-48 switch certification and safety label is located on the bottom of the switch.
Page 104 Summit Switch Models Extreme Networks Consolidated Hardware Guide...
Page 105: Summit Switch Installation
• A minimum of four appropriate screws (not provided) to secure the switch into the rack • # 1 Phillips screwdriver • If you have a Summit7i switch, a minimum of two people to help install the switch into the rack Extreme Networks Consolidated Hardware Guide...
Page 106 Summit Switch Installation CAUTION Do not use the rack mount kits to suspend the switch under a table or desk, or to attach the switch to a wall. To mount the Summit switch in a standard 19-inch (48.26 cm) rack: 1 If you are installing a Summit7i switch, mount the helper bracket in the rack, as shown in Figure 46.
Page 107 Mounting the Switch in a Rack 6 Insert and tighten the screws with a suitable screwdriver, as shown in Figure 47 and Figure 48. Figure 47: An example of fitting the mounting bracket into the switch EW_rack Extreme Networks Consolidated Hardware Guide...
Page 108 10 Connect the Summit switch to a redundant power supply (if applicable). 11 To turn on power to the system, connect the AC power cable(s) to the switch and then to the wall outlet(s). For the Summit4 switches, turn the on/off switch to the on position.
Page 109: Placing The Switch On A Table Or Shelf
• The MGMT LED flashes until the switch successfully passes the POST If the switch passes the POST, the MGMT LED blinks at a slow rate (one blink per second). If the switch fails the POST, the MGMT LED shows a solid yellow light.
Page 110 4 To turn the power supply on, connect the AC power cable to the power supply and then to the wall outlet. WARNING! Do not plug in the power cable into the power supply unless the power supply is installed. 5 Keep the faceplate and the power supply packaging for future use. 48i1_01 48i1_02 Extreme Networks Consolidated Hardware Guide...
Page 111: Installing The Ac Power Cable Retaining Bracket
To install an AC power cable retaining bracket: 1 Disconnect the power cable from the switch and the power source. 2 Remove the two retaining screws from the power socket on the rear of the switch using a #2 Phillips screwdriver.
Page 112: Removing The Ac Power Cable Retaining Bracket From A Power Cable
Summit Switch Installation 6 Tighten the retaining bracket screw. If your switch has two power supplies, install the second retaining bracket now by repeating the preceding steps. Align the retaining brackets as shown in Figure 52 so that the retaining bracket screws do not interfere with each other.
Page 113: Removing The Switch From A Rack
• A minimum of four appropriate screws to secure the helper bracket (not provided) • # 1 Phillips screwdriver • If you have a Summit7i switch, a minimum of two people to help remove the switch from the rack To remove the Summit switch from a standard 19-inch (48.26 cm) rack: 1 Unplug the power cable(s) from the from the wall outlet(s) and then from the switch.
Page 114 Summit Switch Installation Extreme Networks Consolidated Hardware Guide...
Page 115: Part 4 Alpine Switch
Part 4 Alpine Switch...
Page 117: Alpine 3800 Series Switch Overview
Reference Guide. The features of the Alpine 3800 series switch include: • A 9-slot chassis that can be populated with up to eight input/output (I/O) modules and one Switch Management Module (SMMi) (Alpine 3808) • A 5-slot chassis that can be populated with up to four I/O modules and one SMMi (Alpine 3804) •...
Page 118: Port Connections
Avoid direct eye exposure to beam. Table 34: Port configurations available on Alpine I/O modules Ethernet Ports 10BASE-T/ 100BASE-TX/ Module 100BASE-TX 1000BASE-T GM-4Ti GM-4Xi GM-4Si GM-WDMi GM-16X GM-16T FM-32Ti FM-24Ti GBIC 1000BASE-SX 100BASE-FX OTHER 1 WDM 16 Mini-GBIC Extreme Networks Consolidated Hardware Guide...
Page 119: Switch Components
5 The FM-8Vi has eight internal loopback ports for rate shaping. Module supports 10BASE-S. Switch Components There are three models in the Alpine 3800 series: the Alpine 3808 switch, the Alpine 3804 switch, and the Alpine 3802 switch. This section describes the three Alpine models.
Page 120: Alpine 3802 Switch
1 All installation, maintenance, and removal of a power supply must be done by qualified, trained service personnel only. 2 If you have one AC power supply installed in the Alpine 3802 switch, it must be installed in the lower power supply tray (PSU A).
Page 121 • All service to components of an Alpine 3800 series switch should be performed by trained service personnel only. Service personnel are persons having appropriate technical training and experience necessary to be aware of the hazards to which they are exposed in performing a task and of measures to minimize the danger to themselves or other persons.
Page 122 Alpine 3800 Series Switch Overview Extreme Networks Consolidated Hardware Guide...
Page 123: Alpine 3800 Series Architecture
Alpine 3800 Series Switch Chassis There are three models in the Alpine 3800 series: the Alpine 3808 switch, the Alpine 3804 switch, and the Alpine 3802 switch. This chapter describes: • Alpine 3800 Series Architecture on page 123 • Installing the Chassis on page 132 —...
Page 124: Chapter 7 Alpine 3800 Series Switch Chassis
Alpine 3800 Series Switch Chassis • One electromagnetic discharge (ESD) wrist strap connector The Alpine 3808 switch can support up to the following number of ports and types of port configurations: • 256 switched 10BASE-T/100BASE-TX Ethernet ports • 192 switched 100BASE-FX Fast Ethernet ports •...
Page 125: Alpine 3808 Switch Rear View
Alpine 3800 Series Architecture Alpine 3808 Switch Rear View Figure 54 shows the rear view of the Alpine 3808 switch. Figure 54: Rear view of the Alpine 3808 switch Label Grounding studs 38_rear8 The rear view of the Alpine 3808 switch provides: •...
Page 126 Alpine 3800 Series Switch Chassis The Alpine 3804 switch can support up to the following number of ports and types of port configurations: • 128 switched 10BASE-T/100BASE-TX Ethernet ports • 96 switched 100BASE-FX Fast Ethernet ports • 16 switched Gigabit Ethernet ports •...
Page 127: Alpine 3804 Switch Rear View
• One fan tray • One electromagnetic discharge (ESD) wrist strap connector • Six light emitting diode (LED) displays The Alpine 3802 switch can support up to the following number of ports and types of port configurations: • 64 switched 10BASE-T/100BASE-TX Ethernet ports •...
Page 128 Alpine Ethernet I/O modules (green stripe) and Alpine Access I/O modules (silver stripe). • Auto—The switch determines if it is in standard or extended mode depending on the type of modules installed in the chassis or the slot preconfigurations.
Page 129 STANDARD MODE Green NOTE The Alpine 3802 switch has an integrated Switch Management Module that is located in the chassis.The module is not hot-swappable or user-removable. Do not attempt to remove. Contact Extreme Networks Customer Support if you experience problems.
Page 130: Alpine 3802 Switch Rear View
NOTE Do not attempt to fix a failed power supply; power supplies are not user removable. Alpine 3802 switch power supplies must be installed or removed by trained service personnel only. Contact Extreme Networks Customer Support if you experience problems.
Page 131 Alpine 3802 DC Rear View For centralized DC power connections, install only in a restricted access area. Figure 59: Rear view of the Alpine 3802 switch with dual DC power supplies Grounding studs The rear view of the Alpine 3802 DC switch provides: •...
Page 132: Installing The Chassis
Alpine 3804 Alpine 3802 The Alpine 3808 and Alpine 3804 chassis are shipped with a preinstalled fan tray. For your safety, due to the increased weight of the chassis after components are installed and to prevent damage to the equipment, Extreme Networks strongly recommends that you install the power supply and modules after you mount the chassis in a rack.
Page 133: Rack Installation
• Helper bracket (provided) • A minimum of four appropriate screws to secure the helper bracket (not provided) • If you have an Alpine 3808 or 3804, a minimum of eight appropriate screws (not provided) to secure the chassis into the rack •...
Page 134 • Alpine 3808 is shown in Figure 62 • Alpine 3804 is shown in Figure 63 • Alpine 3802 is shown in Figure 64 Figure 62: The Alpine 3808 chassis requires 8 screws to be securely mounted in a rack Helper bracket...
Page 135: Grounding The Alpine 3800 Series Chassis
• One Panduit-style, standard two-hole barrel, copper compression lug • AWG, high strand-count copper wire cable, appropriate for your chassis — 8 AWG for the Alpine 3808 — 10 AWG for the Alpine 3804 — 14 AWG for the Alpine 3802...
Page 136: Removing The Chassis
3 To reduce weight and prevent possible equipment damage, use a # 1 Phillips screwdriver to remove the: • Power supply, SMMi, and I/O modules from the Alpine 3808 and Alpine 3804 • I/O modules from the Alpine 3802 For information about removing power supplies, see Chapter 8.
Page 137 Power Supplies This chapter describes: • Installing the Alpine 3808 and the Alpine 3804 AC Power Supply on page 139 • Removing the Alpine 3808 and the Alpine 3804 AC Power Supply on page 141 • Supplying Power to the Alpine 3802 AC Power Supply on page 142 •...
Page 138: Chapter 8 Alpine 3800 Series Switch Power Supplies
1 All installation, maintenance, and removal of a power supply must be done by qualified, trained service personnel only. 2 If you have one AC power supply installed in the Alpine 3802 switch, it must be installed in the lower power supply tray (PSU A).
Page 139: Installing The Alpine 3808 And The Alpine 3804 Ac Power Supply
Installing the Alpine 3808 and the Alpine 3804 AC Power Supply This section describes how to install an AC power supply for either the Alpine 3808 or the Alpine 3804 switch. The Alpine 3802 switch power supply is preinstalled at the factory.
Page 140 Alpine 3800 Series Switch Power Supplies Figure 65: AC power supply for the Alpine 3808 switch Ejector/ injector lever Handle WHEN INSTALLED IN 3808 THIS WAY UP THIS 3804 DC OK Figure 66: AC power supply for the Alpine 3804 switch...
Page 141: Verifying A Successful Installation
I/O module LED activity. Removing the Alpine 3808 and the Alpine 3804 AC Power Supply You need the following tools and equipment to remove the Alpine 3808 and the Alpine 3804 AC power supplies: • ESD-preventive wrist strap...
Page 142: Supplying Power To The Alpine 3802 Ac Power Supply
6 If you are going to install a replacement power supply, follow the installation steps on page 139. 7 If there is a problem with the power supply that you removed, contact Extreme Networks for assistance.
Page 143: Verifying A Successful Installation
I/O module LED activity. Installing the Alpine 3808 and the Alpine 3804 DC Power Supply This section describes the steps to successfully install and power your Alpine 3808 or Alpine 3804 DC power supply: • Selecting the cabling •...
Page 144: Selecting The Cabling
Power Installing the Power Supply This section describes how to install a DC power supply for both the Alpine 3808 switch and the Alpine 3804 switch. The Alpine 3802 switch comes with DC power supplies that are preinstalled at the factory; however, you must attach the cabling to the DC power supplies.
Page 145 • Ground the chassis—For more information about grounding the chassis, see “Grounding the Alpine 3800 Series Chassis” on page 135. You need the following tools and equipment to install the Alpine 3808 and the Alpine 3804 DC power supplies: • ESD-preventive wrist strap •...
Page 146 Alpine 3800 Series Switch Power Supplies Figure 68: DC power supply for the Alpine 3804 switch Safety On/off latch switch Handle 45022 WHEN INSTALLED IN 3804 THIS WAY UP THIS -48V SERVICE REMOVE SLIDE 45022 CAUTION When you insert a power supply, use one hand to support the power supply from the bottom and the other hand to hold the central handle on the front of the power supply.
Page 147: Attaching The Cabling And Supplying Power
Figure 70: Alpine 3804 DC power supply with cables CAUTION Ensure that no copper is visible between the lug and the cable insulation. Extreme Networks Consolidated Hardware Guide Installing the Alpine 3808 and the Alpine 3804 DC Power Supply 45022 SLIDE TO REMOVE...
Page 148: Verifying A Successful Installation
I/O module LED activity. Removing the Alpine 3808 and the Alpine 3804 DC Power Supply You need the following tools and equipment to remove the Alpine 3808 and the Alpine 3804 DC power supplies: • ESD-preventive wrist strap •...
Page 149: Supplying Power To The Alpine 3802 Dc Power Supply
8 If you are going to install a replacement power supply, follow the installation steps on page 144. 9 If there is a problem with the power supply that you removed, contact Extreme Networks for assistance.
Page 150: Selecting The Cabling
• Ground the chassis—For more information about grounding the chassis, see “Grounding the Alpine 3800 Series Chassis” on page 135. In the event of a power supply failure, please contact Extreme Networks about servicing and replacing your power supply. NOTE Alpine 3802 power supplies must be removed and replaced by personnel that have been trained by Extreme Networks and in accordance with all local and national electrical codes.
Page 151: Verifying A Successful Installation
• The MGMT LED flashes until the switch successfully passes the POST If the switch passes the POST, the MGMT LED blinks at a slow rate (one blink per second). If the switch fails the POST, the MGMT LED shows a solid yellow light.
Page 152 Alpine 3800 Series Switch Power Supplies Extreme Networks Consolidated Hardware Guide...
Page 153: Alpine 3800 Series Switch Management Module
Switch Management Module (SMMi). The Switch Management Module (SMMi) is responsible for upper-layer protocol processing and switch management functions in the Alpine 3808 and Alpine 3804 chassis. The SMMi can store two ExtremeWare software images (version 6.0 or later) and two switch configurations.
Page 154: Smmi Memory
The SMMi has two 144-pin SODIMM sockets, and ships with two 128 MB SODRAM modules installed, as shown in Figure 73. NOTE The SMMi supports only the SODIMMs that are supplied by Extreme Networks. Figure 73: SMMi SODIMM sockets SMMi LEDs Table 43 describes the LED activity on the SMMi.
Page 155: Installing Smmi Modules
This is where you install the SMMi. CAUTION You can install the SMMi in the designated, top (orange) slot of the Alpine 3808 or 3804 chassis only. SMMi modules do not fit in numbered slots. Forceful insertion can damage the module.
Page 156: Verifying The Smmi Module Installation
1 Attach the ESD strap that is provided to your wrist and connect the metal end to the ground receptacle that is located on the top-right corner of the switch front panel. 2 Use a #2 Phillips screwdriver to unscrew the two captive screws.
Page 157 4 To install a replacement SMMi, follow the installation procedure described on page 155. 5 Leave the ESD strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated Hardware Guide Removing SMMi Modules...
Page 158 Alpine 3800 Series Switch Management Module Extreme Networks Consolidated Hardware Guide...
Page 159: Alpine 3800 Series I/O Modules
Specifications.” Configuring I/O Modules No configuration information is stored on the I/O modules; configuration information is stored on the SMMi for the Alpine 3808 and 3804 chassis and the integrated Switch Management Module in the Alpine 3802 chassis. NOTE There is a slight difference in appearance between Alpine I/O modules. Alpine Ethernet I/O modules have a green stripe along the side of the module.
Page 160 If you pre-configure a slot for a specific module type, and then insert a different type of module, the module reverts to its default configuration. NOTE See the ExtremeWare Software User Guide and the ExtremeWare Command Reference Guide for more information about configuring I/O modules. Extreme Networks Consolidated Hardware Guide...
Page 161: Gm-4Ti Module
The GM-4Ti module has the following LEDs: • Module status • Port status • Port speed For information about the LEDs and their activity on the GM-4Ti module, see “I/O Module LEDs” on page 183. Extreme Networks Consolidated Hardware Guide...
Page 162: Gm-4Xi Module
Table 44: GBIC types and maximum distances Standard Media Type 50/125 µm multimode fiber (850 nm optical window) 50/125 µm multimode fiber 62.5/125 µm multimode fiber 62.5/125 µm multimode fiber Gigabit Ethernet ports Mhz•Km Maximum Rating Distance (Meters) 38_GM4X Extreme Networks Consolidated Hardware Guide...
Page 163 LX100 (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. If you have an Alpine 3800 series switch populated with a GM-4Xi module, do one of the following: •...
Page 164 Alpine 3800 Series I/O Modules LEDs The GM-4Xi module has the following LEDs: • Module status • Port status For information about the LEDs and their activity on the GM-4Xi module, see “I/O Module LEDs” on page 183. Extreme Networks Consolidated Hardware Guide...
Page 165: Gm-4Si Module
The GM-4Si module has the following LEDs: • Module status • Port status For information about the LEDs and their activity on the GM-4Si module, see “I/O Module LEDs” on page 183. Extreme Networks Consolidated Hardware Guide 1000 Mbps ports Minimum Typical Maximum -9.5 dBm...
Page 166: Gm-Wdmi Module
Total system budget 4 Gbps port Typical Maximum -3 dBm -1 dBm 1501 nm 1507 nm 1521 nm 1527 nm 1541 nm 1547 nm 1561 nm 1567 nm -1 dBm -25 dB 12 dBm 38_GMWDM Extreme Networks Consolidated Hardware Guide...
Page 167 Extreme Networks recommends that you reserve 3 dB for losses due to cable splices, connectors, and operating margin. Table 47 describes the cable attenuation, cable budget, and operating distance for a variety of cable attentuation ratings for the GM-WDMi module.
Page 168: Gm-16X 3 Module
4:1 to the Alpine backplane. The module has four groups of four ports each. Each group multiplexes traffic into a single full duplex gigabit link to the switch fabric. To take advantage of this architecture, use a single port in each group before using all of the ports in any particular group.
Page 169 4 Gigabits to the Alpine backplane. When a GM-16X an Alpine 3808, and five or more ports of ports 1 through 8 or ports 9 through 16 are simultaneously forwarding unusually high rates of small, uniformly sized packets (for example, 64 Byte), the bandwidth through each port can be lower than the expected minimum of 250 Mbps.
Page 170: Gm-16T 3 Module
4:1 to the Alpine backplane. The module has four groups of four ports each. Each group multiplexes traffic into a single full duplex gigabit link to the switch fabric. To take advantage of this architecture, use a single port in each group before using all of the ports in any particular group.
Page 171 4 Gigabits to the Alpine backplane. When a GM-16T an Alpine 3808, and five or more ports of ports 1 through 8 or ports 9 through 16 are simultaneously forwarding unusually high rates of small, uniformly sized packets (for example, 64 Byte), the bandwidth through each port can be lower than the expected minimum of 250 Mbps.
Page 172: Fm-32Ti Module
The FM-32Ti module has the following LEDs: • Module status • Port status For information about the LEDs and their activity on the FM-32Ti module, see “I/O Module LEDs” on page 183. 10/100 Mbps ports 38_FM32T Extreme Networks Consolidated Hardware Guide...
Page 173: Fm-24Ti Module
• Directly by using a cable that is terminated with 12 RJ-45 connectors. The RJ-21 connector is shown in Figure 83. Figure 83: RJ-21 connector Screws secure connector to port Extreme Networks Consolidated Hardware Guide 10/100 Mbps ports Cable Min Length Shielded trunk cable with 25...
Page 174 For information about the LEDs and their activity on the FM-24Ti module, see “I/O Module LEDs” on page 183. Software Requirements The FM-24Ti module requires that you load ExtremeWare version 6.1.7 or later and BootROM 6.5 or later on your switch. Extreme Networks Consolidated Hardware Guide...
Page 175: Fm-24Sfi Module
The FM-24SFi module has the following LEDs: • Module status • Port status For information about the LEDs and their activity on the FM-24SFi module, see “I/O Module LEDs” on page 183. Extreme Networks Consolidated Hardware Guide 100 Mbps ports with status LEDs Minimum Typical...
Page 176 Alpine 3800 Series I/O Modules Software Requirements The FM-24SFi module requires that you load ExtremeWare version 6.1.7 or later and BootROM 6.5 or later on your switch. Extreme Networks Consolidated Hardware Guide...
Page 177: Fm-24Mfi Module
The FM-24MFi module has the following LEDs: • Module status • Port status For information about the LEDs and their activity on the FM-24MFi module, see “I/O Module LEDs” on page 183. Extreme Networks Consolidated Hardware Guide 100 Mbps ports with status LEDs Minimum Typical...
Page 178 Alpine 3800 Series I/O Modules Software Requirements The SMMi requires ExtremeWare version 6.1.5 or later to operate the FM-24MFi. Extreme Networks Consolidated Hardware Guide...
Page 179: Fm-8Vi Module
1 blue white 2 orange white 3 green white 4 brown white 5 slate white 6 blue red Extreme Networks Consolidated Hardware Guide VDSL ports ™ strap to secure the connector on the cable to the module. Tip Side Pin number/Wire Color...
Page 180 However, the VDSL ports on the FM-8Vi connect to the Mogul-100 in such a way that the Ethernet port on the Mogul-100 behaves as though it is located on the Alpine switch. When you configure a port on the FM-8Vi, you are configuring the Ethernet port on the Mogul-100. For example, when you add port 2 on the FM-8Vi to a VLAN, the Ethernet port on the Mogul-100 connected to port 2 of the FM-8Vi now belongs to that VLAN.
Page 181: Wm-4T1I Module
The WM-4T1i module requires that you load ExtremeWare version 6.1.5 or later and BootROM 6.5 or later on your switch. For more information about software requirements and WM-4T1i module configuration, see the ExtremeWare Software User Guide and the ExtremeWare Command Reference Guide. Extreme Networks Consolidated Hardware Guide...
Page 182: Wm-4E1I Module
The WM-4E1i module requires ExtremeWare version 6.1.5 or later and BootROM 6.5 or later. For more information about software requirements and WM-4E1i module configuration, see the ExtremeWare Software User Guide and the ExtremeWare Command Reference Guide. Extreme Networks Consolidated Hardware Guide...
Page 183: Wm-1T3I Module
Table 57 describes the LED activity on the Alpine I/O modules with the green stripe (for example, the GM-4Ti, GM-4Xi, and FM-24MFi I/O modules). Table 58 describes the LED activity on the Alpine Access I/O modules with the silver stripe (for example, the WM-4T1i, WM-4E1i, and WM-1T3i I/O modules). Extreme Networks Consolidated Hardware Guide...
Page 184 Physical link is present, higher-layer link is established, and traffic is present Loopback testing mode is in progress Port is active, but disabled No link is present Link is present Traffic is present Extreme Networks Consolidated Hardware Guide...
Page 185: Installing I/O Modules
• Slots numbered 1 through 3 in the Alpine 3802 chassis CAUTION Do not install I/O modules into the top, unnumbered slot of the Alpine 3808 or Alpine 3804 chassis; this slot is designated for SMMi modules only. I/O modules do not fit in the top slot of the Alpine 3808 or the Alpine 3804 chassis.
Page 186: Verifying The I/O Module Installation
• Status of the ports on the module For more information about slot status information, see the ExtremeWare Software User Guide and the ExtremeWare Command Reference Guide. command to display slot-specific command (where <slot> is the show slot <slot> Extreme Networks Consolidated Hardware Guide...
Page 187: Removing I/O Modules
1 Attach the ESD strap that is provided to your wrist and connect the metal end to the ground receptacle that is located on the top-right corner of the switch front panel. 2 Use a #2 Phillips screwdriver to unscrew the two captive screws.
Page 188 Alpine 3800 Series I/O Modules Extreme Networks Consolidated Hardware Guide...
Page 189: Alpine 3800 Series Switch Fan Tray
Do not cover or obstruct the fan ventilation holes at the rear of the unit. Doing so can result in overheating and possible damage to the Alpine 3808 switch. Thermal sensors will shut down the Alpine 3808 switch if the internal temperature exceeds 60 degrees Celsius.
Page 190: Alpine 3804 Fan Tray
ExtremeWare monitors the fan trays in the Alpine 3804 switch for failure and overheat conditions. All fan failures and over temperature events cause the switch to send alerts to the network management station or to the switch log. See the ExtremeWare Software User Guide for more information about switch monitoring.
Page 191: Removing The Alpine 3808 Or Alpine 3804 Fan Tray
Removing the Alpine 3808 or Alpine 3804 Fan Tray Alpine 3808 and Alpine 3804 fan trays are hot-swappable. You do not need to turn off power to an Alpine 3808 or Alpine 3804 switch to remove a fan tray. You need the following tools and equipment to remove a fan tray: •...
Page 192: Installing The Alpine 3808 Or Alpine 3804 Fan Tray
ESD-sensitive components. Installing the Alpine 3808 or Alpine 3804 Fan Tray Alpine 3808 and Alpine 3804 fan trays are hot-swappable. You do not need to turn off power to an Alpine 3808 or Alpine 3804 switch to install a fan tray.
Page 193 4 To secure the fan tray, turn the screws clockwise until they become tight. 5 Leave the ESD strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated Hardware Guide Installing the Alpine 3808 or Alpine 3804 Fan Tray...
Page 194 Alpine 3800 Series Switch Fan Tray Extreme Networks Consolidated Hardware Guide...
Page 195: Part 5 Blackdiamond Switch
Part 5 BlackDiamond Switch...
Page 197: Blackdiamond 6800 Series Switch Overview
This section describes the features of the BlackDiamond family of switches. If the information in the release notes differs from the information in this guide, follow the release notes. For more information about configuring the switch, refer to the ExtremeWare Software User Guide and The ExtremeWare Command Reference Guide.
Page 198: Port Connections
Table 59: Port configurations available on BlackDiamond I/O modules Ethernet Ports 10BASE-T/ 100BASE-T/ Module 100BASE-TX 1000BASE-T G8Ti G8Xi G12SXi G16X G24T WDMi 10GLRi F32T F48Ti GBIC 1000BASE-SX 100BASE-FX OTHER 16 Mini-GBIC 1 10-Gbps 1 10GBASE-LR Extreme Networks Consolidated Hardware Guide...
Page 199: Switch Components
The BlackDiamond 6816 chassis only supports modules with an “i” or “3” in their name, such as the G16X , and power supplies with an “i” in their name, such as the ipower 220 VAC. Extreme Networks Consolidated Hardware Guide 100BASE-T/ 1000BASE-T...
Page 200: Blackdiamond 6808 Switch
Each MSM64i has two CPUs for protocol processing and network management. For full redundancy, you can install up to four MSM64i modules in the BlackDiamond 6816 switch and up to two MSM64i modules in the BlackDiamond 6808 and BlackDiamond 6804 switches.
Page 201: Packet Switching And Routing
MSM64i modules that are installed in the switch. For example, if you install an F48Ti module, it has eight Gigabit Ethernet links to the switch backplane. If you have a BlackDiamond 6816 and install four MSM64i modules, each module receives two of the eight Gigabit Ethernet links.
Page 202 BlackDiamond 6800 Series Switch Overview Extreme Networks Consolidated Hardware Guide...
Page 203: Blackdiamond 6800 Series Architecture
BlackDiamond 6800 Series Switch Chassis There are three models in the BlackDiamond 6800 series: The BlackDiamond 6816 switch, the BlackDiamond 6808 switch, and the BlackDiamond 6804 switch. This chapter describes: • BlackDiamond 6800 Series Architecture on page 203 • Installing the Chassis on page 211 —...
Page 204 • Two side mounted handles for lifting the chassis • One electromagnetic discharge (ESD) wrist strap connector The BlackDiamond 6816 switch can support up to the following number of ports and types of port configurations: • 1344 switched 10BASE-T/100BASE-TX Ethernet ports •...
Page 205: Blackdiamond 6816 Switch Rear View
Figure 92: Front view of the BlackDiamond 6816 switch with sample I/O modules ESD wrist strap connector I/O module slots MSM module slots I/O module slots Power supplies BlackDiamond 6816 Switch Rear View The rear of the BlackDiamond 6816 switch provides: •...
Page 206: Blackdiamond 6808 Switch Front View
BlackDiamond 6800 Series Switch Chassis • Symbols of safety certification Figure 93 shows the rear view of the BlackDiamond 6816 switch. Figure 93: Rear view of the BlackDiamond 6816 switch Grounding studs BD_rr16s BlackDiamond 6808 Switch Front View The BlackDiamond 6808 switch consists of the following components: •...
Page 207 • One fan tray (accessed from the rear of the unit) • One electromagnetic discharge (ESD) wrist strap connector The BlackDiamond 6808 switch can support up to the following number of ports and types of port configurations: • 672 switched 10BASE-T/100BASE-TX Ethernet ports •...
Page 208: Blackdiamond 6808 Switch Rear View
BlackDiamond 6800 Series Switch Chassis Figure 94: Front view of the BlackDiamond 6808 switch with sample I/O modules I/O module slots ESD wrist strap connector POWER Power supplies V-50/60Hz 200-240V, 15A BlackDiamond 6808 Switch Rear View The rear of the BlackDiamond 6808 switch provides: •...
Page 209: Blackdiamond 6804 Switch Front View
• One fan tray (accessed from the front of the unit) • One electromagnetic discharge (ESD) wrist strap connector The BlackDiamond 6804 switch can support up to the following number of ports and types of port configurations: • 384 switched 10BASE-T/100BASE-TX Ethernet ports...
Page 210 I/O module also installed in the chassis in order to operate correctly. Figure 96 shows the front view of the BlackDiamond 6804 chassis installed with two MSM64i modules and four optional I/O modules. Figure 96: Front view of the BlackDiamond 6804 switch with sample I/O modules ESD receptacle module...
Page 211: Blackdiamond 6804 Switch Rear View
• The chassis serial number • The Ethernet MAC address of the switch • Symbols of safety certification Figure 97 shows the rear view of the BlackDiamond 6804 switch. Figure 97: Rear view of the BlackDiamond 6804 switch Installing the Chassis The BlackDiamond 6800 series chassis fits in a standard 19-inch (48.26 cm) rack.
Page 212: Rack Installation
BlackDiamond 6800 Series Switch Chassis equipment, Extreme Networks strongly recommends that you install the power supply and modules after you mount the chassis in a rack. NOTE Mount the chassis in a rack before installing any switch components. Rack Installation To mount the BlackDiamond 6800 series chassis into a standard 19-inch (48.26 cm) rack, you need the...
Page 213 5 While holding the empty chassis, secure it with a minimum of eight suitable screws, depending on the model. • BlackDiamond 6816 is shown in Figure 99 • BlackDiamond 6808 is shown in Figure 100 • BlackDiamond 6804 is shown in Figure 101 Extreme Networks Consolidated Hardware Guide Installing the Chassis...
Page 214 BlackDiamond 6800 Series Switch Chassis Figure 99: Securing the BlackDiamond 6816 chassis in a rack BD_rack16 Extreme Networks Consolidated Hardware Guide...
Page 215 Figure 101: Securing the BlackDiamond 6804 chassis in a rack 6804rack 6 After you secure the chassis, remove the helper bracket. Store it for future use, for example, if you need to remove the chassis. Extreme Networks Consolidated Hardware Guide...
Page 216: Grounding The Blackdiamond 6800 Series Chassis
• A minimum of four appropriate screws to secure the helper bracket (not provided) • # 1 Phillips screwdriver • A minimum of two people to help remove the chassis from the rack ” or ” flathead screwdriver, to 20 in-lbs of torque. Extreme Networks Consolidated Hardware Guide...
Page 217 To uninstall the chassis from a rack: 1 Unplug the power cable from the outlet and then from the switch before you attempt to remove the chassis components and the chassis from the rack. 2 Mount the helper bracket in the rack directly beneath the chassis using four screws that are appropriate for your rack.
Page 218 BlackDiamond 6800 Series Switch Chassis Extreme Networks Consolidated Hardware Guide...
Page 219: Blackdiamond 6800 Series Switch Power Supplies
• One power supply can support a fully loaded BlackDiamond 6804 chassis To increase switch reliability, you can install additional power supplies as needed. If you have three or more power supplies installed in a BlackDiamond 6816 switch or two or more power supplies installed in a BlackDiamond 6808 or BlackDiamond 6804 switch, you can remove one of the power supplies without turning off power to the chassis.
Page 220: 220 Vac Power Supplies
BlackDiamond 6808, and two modules in the BlackDiamond 6804 are powered on. The BlackDiamond switch does not support installing a combination of the old 220 VAC PSUs (part number 50012) with the new iPower 220 VAC PSUs (part number 50021) in the same chassis.
Page 221: 110 Vac Power Supplies
20 A 110 VAC source power connection. The 110 VAC power supply ships with two L5-20P (locking) power cable. Power supplies slide in from the front of the chassis, as illustrated in Figure 103. Extreme Networks Consolidated Hardware Guide DC OUT AC IN...
Page 222: Dc Power Supplies
Figure 104. For centralized DC power connections, install only in a restricted access area. DC OUT AC IN POWER 50020 50020 DC OUT AC IN BD_026 Extreme Networks Consolidated Hardware Guide...
Page 223: Installing A Blackdiamond 6800 Series Power Supply
• # 1 Phillips screwdriver • Power supply NOTE Ground the rack, mount the chassis in a rack, and ground the chassis before installing any switch components. Complete the following tasks before installing any switch components: • Ground the rack—For more information about grounding the rack, see “Protective Grounding for the Rack”...
Page 224 • Ensure that the power supply is right side up • Open the locking handle For the BlackDiamond 6808 or Black Diamond 6804 switch, as shown in Figure 106: • Ensure that the power supply is right side up • Open the locking handle...
Page 225 5 To support the power supply, place both hands under the power supply to check the connectors for dust and packing materials. 6 Gently begin to slide the power supply into the power supply bay. Extreme Networks Consolidated Hardware Guide DC OUT AC IN...
Page 226 To install additional power supplies, repeat steps 1 through 9. Figure 108: Installing a second power supply in a BlackDiamond 6808 or a BlackDiamond 6804 POWER DC OUT AC IN POWER 50021 50021 DC OUT AC IN BD_028 Extreme Networks Consolidated Hardware Guide...
Page 227: Ac Power Cable And Plug
Installing a BlackDiamond 6800 Series Power Supply AC Power Cable and Plug Use the appropriate AC power cable and plug for your switch and your location. See “Wiring Closet Considerations” on page 37 for more information about the types of power cords to use.
Page 228: Preparing The Dc Cabling
2 Insert the cable into the cable lugs. CAUTION Ensure that no copper is visible between the lug and the cable insulation high-strand-count Terminal crimp Area for heat-shrink 0.37 in. tubing (0.94cm) 4 AWG, conductor BD_021 Extreme Networks Consolidated Hardware Guide...
Page 229: Verifying A Successful Installation
Removing a BlackDiamond 6800 Series Power Supply BlackDiamond 6800 series power supplies are hot-swappable. You can add or remove power supplies without turning off power to the chassis and normal operation will continue as long as the switch has enough power to support the installed modules.
Page 230 2 Completely remove the power supply cable(s) from the wall outlet and then from the power supply. If you have a DC power supply, turn the on/off switch to the off position and remove the power cables.
Page 231 Do not handle the power supply using the DC output bus bars. 6 Leave the ESD strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated Hardware Guide Removing a BlackDiamond 6800 Series Power Supply DC OUT...
Page 232 BlackDiamond 6800 Series Switch Power Supplies Extreme Networks Consolidated Hardware Guide...
Page 233: Blackdiamond 6800 Series Management Switch Module
Read the information in this chapter thoroughly before you attempt to install or remove the BlackDiamond Management Switch Fabric Module (MSM64i). The Management Switch Fabric Module (MSM64i) is the internal switch fabric for data that is being sent between I/O modules. One MSM64i is required for switch operation; however, adding more MSM64i modules increases both reliability and throughput.
Page 234 • Modem port—Used to connect a modem for remote access to the CLI. • PCMCIA slot—Reserved for future use. See Chapter 1, “Summary of Common Switch Features” for more information about management ports, and for more information about BlackDiamond MSM64i module specifications, see Appendix C, “Module Technical Specifications.”...
Page 235: Msm64I Activity
Packet handling is distributed among the CPUs of all installed MSM64i modules. When you save the switch configuration, it is saved to all MSM64i modules. If you download a new ExtremeWare image, the image is downloaded to all MSM64i modules.
Page 236: Msm64I Leds
Environment (temperature, fan, power supply) is operating properly Environmental failure has occurred A critical software error has been logged since power Normal operation is occurring Link is down Link is up Packet activity is occurring EW_SODMs Extreme Networks Consolidated Hardware Guide...
Page 237: Installing Msm64I Modules
To reset the critical software error LED (amber ERR LED), use the reboot the switch. If you continue to have critical software errors, or the ERR LED is amber after the command and a switch reboot, contact Extreme Networks Customer Support.
Page 238 • Module name at the top • PCB to the right • Ejector/injector levers are extended Figure 118: MSM64i prior to insertion in a BlackDiamond 6808 50015 CONSOLE MODEM MGMT LINK / ACTIVITY PCMCIA EW_clips EW_clips2 Extreme Networks Consolidated Hardware Guide...
Page 239: Verifying The Msm64I Module Installation
CAUTION Depending on the size and complexity of your network, you should install and configure a slave MSM64i module when there will be minimal network disruption. You may need to reboot your switch after you use the synchronize 6 Store the module packaging for future use.
Page 240: Removing Msm64I Modules
237. 5 Leave the ESD strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. To remove additional MSM64i modules, repeat steps 1 through 4. Extreme Networks Consolidated Hardware Guide...
Page 241: Blackdiamond 6800 Series I/O Modules
BlackDiamond I/O modules consist of a printed circuit board mounted on a metal panel that acts as the insertion vehicle in a BlackDiamond 6800 series switch. The module carrier also includes ejector/injector levers and captive retaining screws at each end of the module front panel.
Page 242 BlackDiamond 6800 Series I/O Modules NOTE See the ExtremeWare Software User Guide and the ExtremeWare Command Reference Guide for more information about configuring I/O modules. Extreme Networks Consolidated Hardware Guide...
Page 243: G8Ti Module
The G8Ti module has the following LEDs: • Module status • Port status • Port speed For information about the LEDs and their activity on the G8Ti module, see “I/O Module LEDs” on page 277. Extreme Networks Consolidated Hardware Guide...
Page 244: G8Xi Module
The G8Xi module supports any of the following GBICs: • 1000BASE-SX • 1000BASE-LX • 1000BASE-LX70 • ZX GBIC • LX100 GBIC • UTP GBIC GBIC Media Types and Distances. Table 69 describes the media types and associated maximum distances for each GBIC type. Extreme Networks Consolidated Hardware Guide...
Page 245 (1550 nm optical window) LX100 (1550 nm optical window) *Extreme Networks proprietary. Connections between two Extreme Networks 1000BASE-LX interfaces can use a maximum distance of 10,000 meters. NOTE For more information about the supported GBIC types, see “GBIC Specifications” on page 25.
Page 246: G12Sxi Module
For information about the LEDs and their activity on the G12SXi module, see “I/O Module LEDs” on page 277. Software Requirements The G12SXi module requires that you load ExtremeWare version 6.1.4 or later on the switch. Extreme Networks Consolidated Hardware Guide...
Page 247: G16X 3 Module
The module has eight groups of two ports each. Each group multiplexes traffic into a single full duplex gigabit link to the switch fabric. To take advantage of this architecture, use a single port in each group before using all of the ports in any particular group.
Page 248 ExtremeWare version 7.0.1b11 or later and BootROM 7.8 or later on the switch. Hardware Requirements The G16X requires a BlackDiamond chassis using MSM64i switch fabric module(s). Maximum Distance (meters) 10,000 70,000 module, see “I/O Module LEDs” on Extreme Networks Consolidated Hardware Guide module.
Page 249 Table 72: G16X modules supported Chassis BlackDiamond 6804 BlackDiamond 6808 BlackDiamond 6808 BlackDiamond 6816 Extreme Networks Consolidated Hardware Guide modules that you can install in a BlackDiamond chassis depending Power Supply G16X Module original power supplies iPower power supplies iPower power supplies Configuring I/O Modules modules.
Page 250: G24T 3 Module
4:1 to the module’s switch fabric. The module has six groups of four ports each. Each group multiplexes traffic into a single full duplex gigabit link to the switch fabric. To take advantage of this architecture, use the same number of ports in each group. Table 73 lists the groups for the G24T module.
Page 251 Table 74: G24T modules supported Chassis BlackDiamond 6804 BlackDiamond 6808 BlackDiamond 6808 BlackDiamond 6816 Extreme Networks Consolidated Hardware Guide modules that you can install in a BlackDiamond chassis depending Power Supply G24T Module original power supplies iPower power supplies iPower power supplies Configuring I/O Modules module, see “I/O Module LEDs”...
Page 252: Wdmi Module
1535 nm Channel 4 wavelength 1555 nm Receiver Optical input power sensitivity -17 dBm Typical Maximum -3 dBm -1 dBm 1501 nm 1507 nm 1521 nm 1527 nm 1541 nm 1547 nm 1561 nm 1567 nm Extreme Networks Consolidated Hardware Guide...
Page 253 Fiber Optic Cable Back reflection Extreme Networks recommends that you reserve 3 dB for losses due to cable splices, connectors, and operating margin. Table 76 describes the cable attenuation, cable budget, and operating distance for a variety of cable attentuation ratings for the WDMi module...
Page 254: 10Glri Module
Table 77 summarizes the optical parameters for the 10GLRi module. Table 77: 10GLRi optical parameters Parameter Value Minimum launch power -6.2 dBm Maximum receiver -12.6 dB sensitivity Minimum extinction ratio 3.5 dB Minimum distance 10 km Wavelength range 1260 to 1355 nm XM_042 Extreme Networks Consolidated Hardware Guide...
Page 255 277. Software Requirements The 10GLRi module requires that you load ExtremeWare 7.0 or later on the switch. Augmented Command. The automatic interface configuration command now includes a keyword to specify the 10 Gigabit Ethernet interface. To configure the automatic interface costs for 10 Mbps, 100 Mbps, 1 Gbps, and 10 Gbps interfaces, use the following command: config ospf metric-table 10m <cost>...
Page 256 The following example configures the automatic interface costs for 10 Mbps, 100 Mbps, 1 Gbps, and 10 Gbps interfaces: config ospf metric-table 10m 20 100m 10 1g 8 10g 4 For more information about this and other ExtremeWare commands, see the ExtremeWare Software Command Reference Guide. Extreme Networks Consolidated Hardware Guide...
Page 257: F48Ti Module
For information about the LEDs and their activity on the F48Ti module, see “I/O Module LEDs” on page 277. Software Requirements The F48Ti module requires that you load ExtremeWare version 6.1.4 or later on the switch. Extreme Networks Consolidated Hardware Guide 52011...
Page 258: F96Ti Module
Port 5 Port 4 Port 3 Port 2 Port 1 Spare Port 12 Port 11 Port 10 Port 9 Port 8 Port 7 Port 6 Port 5 Port 4 Port 3 Port 2 Port 1 BD_037 Extreme Networks Consolidated Hardware Guide...
Page 259 RxD (-) TxD (-) RxD (-) TxD (-) RxD (-) TxD (-) Extreme Networks Consolidated Hardware Guide RJ-45 Pin Numbers 2, 6, 1, 3 2, 6, 1, 3 2, 6, 1, 3 2, 6, 1, 3 2, 6, 1, 3...
Page 260 For information about the module status LED and its activity on the F96Ti module, see “I/O Module LEDs” on page 277. Output Signal RxD (+) TxD (+) Min Length Max Length 100 m XM_046 Max Torque 4 in-lbs Extreme Networks Consolidated Hardware Guide...
Page 261 The F96Ti module requires a BlackDiamond chassis using MSM64i switch fabric module(s). Extreme Networks recommends using iPower power supplies (part numbers 50020, 50021, 50022) with F96Ti modules in a BlackDiamond 6800 chassis. A BlackDiamond 6800 chassis with the original power supplies (part number 50012) will not fewer F96Ti modules than a chassis with iPower power supplies.
Page 262: F32Fi Module
For information about the LEDs and their activity on the F32Fi module, see “I/O Module LEDs” on page 277. Software Requirements The F32Fi module requires that you load ExtremeWare version 6.1.8 or later and BootROM 6.5 or later on the switch. Extreme Networks Consolidated Hardware Guide...
Page 263: P3Csi, P3Cmi, P12Csi, And P12Cmi Modules
The P3cSi and the P12cSi modules support single mode fiber-optic cable only, and the P3cMi and the P12cMi modules support multimode fiber-optic cable only. These modules connect the switch to a SONET infrastructure that is used by metropolitan area service providers and operators of server co-location networks.
Page 264 BlackDiamond 6800 Series I/O Modules In the first application, the metropolitan area network service provider can build service network sites in various cities, then use PoS modules in a BlackDiamond 6800 series switch to connect those cities to a carrier’s SONET infrastructure.
Page 265 Service Ports. The PoS modules are equipped with two front-panel service ports: one port is a subminiature DB-9 connector; the other is a micro HD-15 connector (see Figure 133). Both ports are reserved for use only by Extreme Networks technical support personnel for diagnostic purposes. Extreme Networks Consolidated Hardware Guide...
Page 266 PoS modules installed in a BlackDiamond chassis require at least one BlackDiamond Ethernet I/O module also installed in the chassis in order to operate correctly. Module status LED Module diagnostics LED Network processors and heat sinks General Purpose Processor (GPP) PoS_002 Extreme Networks Consolidated Hardware Guide...
Page 267: Arm
• Processing the frames. • Transmitting the frames back into the switch fabric which then sends them to the appropriate I/O module. A maximum of four ARM modules can be placed in a BlackDiamond 6800 series switch at any one time. Physical Description This section describes the components and the LEDs of the ARM module, as shown in Figure 135.
Page 268 Service Ports. The ARM module is equipped with two front-panel service ports: one port is a DB-9 connector; the other is a micro HD-15 connector (see Figure 135). Both ports are reserved for use only by Extreme Networks technical support personnel for diagnostic purposes. Figure 135: Showing the components and LEDs of the ARM module...
Page 269 ARM module, consult your release notes. ARM modules installed in a BlackDiamond chassis require at least one BlackDiamond Ethernet I/O module also installed in the chassis in order to operate correctly. Extreme Networks Consolidated Hardware Guide...
Page 270: Mpls Module
• Processing the frames. • Transmitting the frames back into the switch fabric which then sends them to the appropriate I/O module. A maximum of four MPLS modules can be placed in a BlackDiamond 6800 series switch at any one time. Physical Description This section describes the components and the LEDs of the MPLS module, as shown in Figure 137.
Page 271 DB-9 connector; the other is a micro HD-15 connector (see Figure 137). The ports are reserved for use only by Extreme Networks technical support personnel for diagnostic purposes. Figure 137: Showing the components and LEDs of the MPLS module...
Page 272 MPLS module, consult your release notes. MPLS modules installed in a BlackDiamond chassis require at least one BlackDiamond Ethernet I/O module also installed in the chassis in order to operate correctly. Extreme Networks Consolidated Hardware Guide...
Page 273: A3Csi And A3Cmi Modules
Enterprise ATM network and an Ethernet backbone. In the first application, the metropolitan area network service provider can build service network sites in various cities, then use ATM modules in a BlackDiamond 6800 series switch to connect those cities to a carrier’s ATM infrastructure.
Page 274 • Two high-performance network processors • A GPP subsystem The network processors are programmable devices that participate with the Extreme “i” chipset to support expanded functionality, features, and flexibility. The GPP subsystem handles system control and I/O module management functions. The GPP subsystem resides outside of the I/O module data path to optimize performance.
Page 275 The ATM module is equipped with two front-panel service ports: one port is a DB-9 connector; the other is a micro HD-15 connector (see Figure 139). Both ports are reserved for use only by Extreme Networks technical support personnel for diagnostic purposes.
Page 276 ATM module, consult your release notes. ATM modules installed in a BlackDiamond chassis require at least one BlackDiamond Ethernet I/O module also installed in the chassis in order to operate correctly. Extreme Networks Consolidated Hardware Guide...
Page 277: I/O Module Leds
1 If you have a PoS module, the link is up, but the PPP/VLAN interface might not be up. To determine whether PPP is up, use show ppp command to display PPP status information. Extreme Networks Consolidated Hardware Guide Indicates Normal operation...
Page 278: Installing I/O Modules
2 Attach the ESD strap that is provided to your wrist and connect the metal end to the ground receptacle that is located on the top-left corner of the switch front panel. 3 Remove the blank faceplate from the slot to make room for the module, if applicable.
Page 279: Verifying The I/O Module Installation
When the I/O module and its ports (if applicable) are configured and operating normally, the front-panel LED indicators should appear as follows: • STATUS LED—green blinking • DIAG LED—off Extreme Networks Consolidated Hardware Guide Verifying the I/O Module Installation command to show slot <slot number>...
Page 280: Displaying Slot Status Information
• ESD-preventive wrist strap • # 1 Phillips screwdriver • Replacement I/O module or blank faceplate if you are not replacing the I/O module (where <slot> is the show slot <slot> also displays that show slot <slot> Extreme Networks Consolidated Hardware Guide...
Page 281 1 Attach the ESD strap that is provided to your wrist and connect the metal end to the ground receptacle that is located on the top-left corner of the switch front panel. 2 Use a #1 Phillips screwdriver to unscrew the two captive screws.
Page 282 BlackDiamond 6800 Series I/O Modules Extreme Networks Consolidated Hardware Guide...
Page 283: Chapter 17 Blackdiamond 6800 Series Switch Fan Tray
ExtremeWare monitors the fan trays in the BlackDiamond 6816 switch for failure and overheat conditions. All fan failures and over temperature events cause the switch to send alerts to the network management station or to the switch log. See the ExtremeWare Software User Guide for more information on switch monitoring.
Page 284: Blackdiamond 6808 Fan Tray
ExtremeWare monitors the fan trays in the BlackDiamond 6808 switch for failure and overheat conditions. All fan failures and over temperature events cause the switch to send alerts to the network management station or to the switch log. See the ExtremeWare Software User Guide for more information on switch monitoring.
Page 285: Blackdiamond 6804 Fan Tray
ExtremeWare monitors the fan trays in the BlackDiamond 6804 switch for failure and overheat conditions. All fan failures and over temperature events cause the switch to send alerts to the network management station or to the switch log. See the ExtremeWare Software User Guide for more information on switch monitoring.
Page 286: Removing A Blackdiamond 6800 Series Fan Tray
2 For the BlackDiamond 6816 switch or the BlackDiamond 6804 switch, use a #1 Phillips screwdriver to unscrew the two screws that secure the fan tray on the front of the chassis.
Page 287 Figure 143. This action disconnects the power to the fan tray. For the BlackDiamond 6808 switch, grasp the edges of the two handles on the front of the fan tray to pull it straight out of the chassis approximately ½ inch (12.7 mm), as shown in Figure 144. This action disconnects power to the fan tray.
Page 288: Installing A Blackdiamond 6800 Series Fan Tray
• # 1 Phillips screwdriver • Replacement fan tray CAUTION Only trained service personnel should perform service to BlackDiamond fan trays. Before installing or removing any components, or carrying out any maintenance procedures, see Appendix A. BD_fanx Extreme Networks Consolidated Hardware Guide...
Page 289 For the BlackDiamond 6808 switch, use both hands to hold the fan tray handles and use the two pins located on each side of the fan tray to guide the fan tray into the bay. Gently begin to insert the new fan tray into the bay.
Page 290 BlackDiamond 6800 Series Switch Fan Tray Extreme Networks Consolidated Hardware Guide...
Page 291: Part 6 Switch Operation
Part 6 Switch Operation...
Page 293: Connecting Equipment To The Console Port
• Flow control—XON/XOFF The terminal or PC with terminal-emulation software that you connect to any Summit, Alpine, or BlackDiamond switch must be configured with these settings. This procedure is described in the documentation supplied with the terminal. Appropriate cables are available from your local supplier, or you can make your own. To ensure the electromagnetic compatibility of the unit, only shielded serial cables should be used.
Page 294 Figure 146: PC-AT serial null-modem cable pinouts Switch Cable connector: 9-pin female Screen Shell Ground Direction PC/Terminal Cable connector: 25-pin male/female Screen Ground 25pin PC-AT Serial Port Cable connector: 9-pin female Shell Screen Ground 9pin Extreme Networks Consolidated Hardware Guide...
Page 295: Logging In For The First Time
Logging In for the First Time After your switch has completed all POSTs, it is operational. When the switch is operational, you can log in and configure an IP address for the default VLAN (named default). To manually configure the IP settings: 1 Connect a terminal or PC with terminal-emulation software to: •...
Page 296 Initial Switch and Management Access Extreme Networks Consolidated Hardware Guide...
Page 297: Part 7
Part 7 Appendixes...
Page 299: Appendix A Safety Information
Important Safety Information WARNING! Read the following safety information thoroughly before installing your Extreme Networks switch. Failure to follow this safety information can lead to personal injury or damage to the equipment. Installation, maintenance, and removal of a switch, chassis, or its components must be done by qualified service personnel only.
Page 300: Power Cable
This information only pertains to the Summit series of switches, with the exception of the Summit7i. The unit automatically adjusts to the supply voltage, and it is suitable for both 110 VAC and 200-240 VAC operation. ), Type SVT or SJT, Extreme Networks Consolidated Hardware Guide...
Page 301: Connections
Fiber Optic ports - Optical Safety. To protect your eyes, never look at the transmit LED/laser through a magnifying device while it is powered on. Never look directly at a fiber port on the switch or at the ends of fiber cable when they are powered on.
Page 302 • The weight of the lithium contained in each coin cell is approximately 0.035 grams. • Two types of batteries are used interchangeably: — CR chemistry uses manganese dioxide as the cathode material. — BR chemistry uses poly-carbonmonofluoride as the cathode material. Extreme Networks Consolidated Hardware Guide...
Page 303 Switch Technical Specifications This appendix describes the technical specifications of the Extreme Networks family of switches: • Summit “i” series switch specifications on page 303 • Summit non-”i” series switch specifications on page 306 • Summit24e2 switch specifications on page 307 •...
Page 304 SX—372 W maximum (1270 BTU/hr maximum) TX—698 W maximum (2382 BTU/hr maximum) Summit48i 140 W maximum (477 BTU/hr maximum) Summit48si 185 W maximum (631 BTU/hr maximum) Power Supplies Summit1i AC Line Frequency 50 Hz to 60 Hz Extreme Networks Consolidated Hardware Guide...
Page 305 AC Line Frequency Input Voltage Options Current Rating Switch Power-Off Temperature power-off Extreme Networks Consolidated Hardware Guide 85 VAC to 250 VAC 100-120/200-240 VAC 3/1.5 A 50 Hz to 60 Hz 100 VAC to 240 VAC 100-120/200-240 VAC 4/2 A...
Page 306 CNS 13438 Class A (Taiwan) Heat Dissipation 140 W maximum (341.2 BTU/hr maximum) Power Supply AC Line Frequency 50 Hz to 60 Hz Input Voltage Options 90 VAC to 264 VAC, auto-ranging Current Rating 100-120/200-240 VAC 3.0/1.5 A Extreme Networks Consolidated Hardware Guide...
Page 307 Certifications and Standards Heat Dissipation Power Supply AC Line Frequency Input Voltage Options Extreme Networks Consolidated Hardware Guide Height: 1.7 inches (4.3 cm) Width: 17.25 inches (43.8 cm) Depth: 8.32 inches (21.1 cm) Weight: 7 lbs (3.2 kg) UL 1950 3rd Edition, listed cUL listed to CAN/CSA-C22.2 #950...
Page 308 GOST (Russia) Heat Dissipation 74 W maximum (252 BTU/hr maximum) Power Supply AC Line Frequency 50 Hz to 60 Hz Input Voltage Options 90 VAC to 264 VAC, auto-ranging Current Rating 100-120/200-240 VAC 2.0/1.0 A Extreme Networks Consolidated Hardware Guide...
Page 309 Heat Dissipation Power Supply AC Line Frequency Input Voltage Options Current Rating Extreme Networks Consolidated Hardware Guide Height: 1.75 inches (4.44 cm) Width: 17.25 inches (43.82 cm) Depth: 21.49 inches (54.58 cm) Weight: 16.75 lbs (7.54 kg) UL 60950 3rd Edition, listed cUL listed to CAN/CSA-C22.2 No.
Page 310 GOST (Russia) Taiwan CNS 13438:1997 Class A (BSMI Approval, Emissions Laser Safety North America FCC 21 CFR subpart (J) (Safety of Laser Products) CDRH Letter of Approval (US FDA Approval) Europe EN60825-2 (European Safety of Lasers) Extreme Networks Consolidated Hardware Guide...
Page 311 Power Supply AC Line Frequency Input Voltage Options Current Rating Switch Power-Off Temperature power-off Extreme Networks Consolidated Hardware Guide Summit 200-24 24.1 W maximum (82 BTU/hr maximum) Summit 200-48 48.0 W maximum (164 BTU/hr maximum) 50 Hz to 60 Hz 90 VAC to 264 VAC, auto-ranging 100-120 VAC 2.0 A...
Page 312 EN6100-3-2, 3-3 VCCI Class A (Japan) AS/NZS 3548 (Australia/New Zealand) NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Telecommunications NEBS/Telcordia, Type IV, Level 3, Issue2 EN/ETSI 300 386-2 v1.1.3 (1997) MIC Telecom Extreme Networks Consolidated Hardware Guide...
Page 313 Alpine 3802 AC Line Frequency Input Voltage Options Current Rating Switch Power-Off Temperature power-off Extreme Networks Consolidated Hardware Guide Alpine 3808 1046 W maximum (3600 BTU/hr maximum) Alpine 3804 577 W maximum (2000 BTU/hr maximum) Alpine 3802 315 W maximum (1076 BTU/hr maximum)
Page 314 EN6100-3-2, 3-3 VCCI Class A (Japan) AS/NZS 3548 (Australia/New Zealand) NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Telecommunications NEBS/Telcordia, Type IV, Level 3, Issue2 EN/ETSI 300 386-2 v1.1.3 (2000) MIC Telecom Extreme Networks Consolidated Hardware Guide...
Page 315 -48 DC Power Supply Input Voltage Options Current Rating Weight Switch Power-Off Temperature power-off Extreme Networks Consolidated Hardware Guide 220 VAC Power Supply 2544 W maximum (8687 BTU/hr maximum) 110 VAC Power Supply 2661 W maximum (9088 BTU/hr maximum) -48 DC Power Supply...
Page 316 -40° to 70 ° C (-40° to 158° F) -10° to 70 ° C (14° to 158° F) (Alpine 3802 only) Operating Humidity 10% to 95% relative humidity, noncondensing Standards: EN60068 to Extreme IEC68 schedule Certification Marks CE (European Community) TUV/GS (German Notified Body) TUV/S (Argentina)
Page 317 • PoS module specifications on page 335 • ARM module specifications on page 336 • MPLS module specifications on page 337 • ATM module specifications on page 338 Specifications common to all modules: • Common Module Specifications on page 339 Extreme Networks Consolidated Hardware Guide...
Page 318: Alpine Modules
NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (1997) Extreme Networks Consolidated Hardware Guide...
Page 319 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.5 inches (3.8 cm) Width: 16.25 inches (41.3 cm) Depth: 8.0 inches (20.3 cm) Weight: 4 lbs (1.8 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 1950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 320 AS/NZS 3548 (Australia/New Zealand) NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) Environmental EN/ETSI 300 019-2-1:2000 class 1.2 EN/ETSI 300 019-2-2:1999 class 2.3 EN/ETSI 300 019-2-2:1999 class 3.1e ASTM D5276 ASTM D3580 ASTM D3332 module specifications module) module) Extreme Networks Consolidated Hardware Guide...
Page 321 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.5 inches (3.8 cm) Width: 16.25 inches (41.3 cm) Depth: 8.0 inches (20.3 cm) Weight: 4 lbs (1.8 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 1950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 322 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (1997) Extreme Networks Consolidated Hardware Guide...
Page 323 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.5 inches (3.8 cm) Width: 16.25 inches (41.3 cm) Depth: 8.0 inches (20.3 cm) Weight: 4 lbs (1.8 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 1950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 324 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (1997) Extreme Networks Consolidated Hardware Guide...
Page 325 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.5 inches (3.8 cm) Width: 16.25 inches (41.3 cm) Depth: 8.0 inches (20.3 cm) Weight: 5 lbs (2.7 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 1950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 326 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (1997) Extreme Networks Consolidated Hardware Guide...
Page 327: Blackdiamond Modules
Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.6 inches (4.1 cm) Width: 15.1 inches (38.4 cm) Depth: 16.0 inches (40.6 cm) Weight: 6.25 lbs (2.81 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 60950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 328 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (2000) Extreme Networks Consolidated Hardware Guide...
Page 329 Safety Certifications and Standards Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Extreme Networks Consolidated Hardware Guide module specifications Height: 1.6 inches (4.1 cm) Width: 15.1 inches (38.4 cm) Depth: 16.0 inches (40.6 cm) Weight: 7.5 lbs (2.81 kg) UL 60950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 330 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (2000) Extreme Networks Consolidated Hardware Guide...
Page 331 RF electric fields Immunity to fast EN 61000-4-4 transients Extreme Networks Consolidated Hardware Guide Height: 1.6 inches (4.1 cm) Width: 15.1 inches (38.4 cm) Depth: 16.0 inches (40.6 cm) Weight: 6.25 lbs (2.81 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 60950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 332 150kHz-80MHz 3V RMS 80% AM (1kHz) 50Hz, 1A/m RMS 30% reduction for 10mS 60% reduction for 100mS >95% for 5000mS 900MHz±5MHz 3V/m, 50% duty cycle, 200Hz replicating frequency Test Performance Specification Criterion Extreme Networks Consolidated Hardware Guide...
Page 333 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.6 inches (4.1 cm) Width: 15.1 inches (38.4 cm) Depth: 16.0 inches (40.6 cm) Weight: 6.25 lbs (2.81 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 60950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 334 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (2000) Extreme Networks Consolidated Hardware Guide...
Page 335 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.6 inches (4.1 cm) Width: 15.1 inches (38.4 cm) Depth: 16.0 inches (40.6 cm) Weight: 5.25 lbs (2.38 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 60950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 336 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (2000) Extreme Networks Consolidated Hardware Guide...
Page 337 Electromagnetic Compatibility (EMC) Certifications and Standards Environmental Telecommunications Extreme Networks Consolidated Hardware Guide Height: 1.6 inches (4.1 cm) Width: 15.1 inches (38.4 cm) Depth: 16.0 inches (40.6 cm) Weight: 5.25 lbs (2.38 kg) NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 UL 60950 3rd Edition, listed accessory cUL listed accessory to CAN/CSA-C22.2 No.
Page 338 NOM/NYCE (Mexico) MIC Mark (Korea) GOST (Russia) CNS 13438 Class A (Taiwan) Environmental NEBS/Telcordia, Type IV, Level 3, GR-63 Issue2 EN/ETSI 300 019 Telecommunications NEBS/Telcordia, Type IV, Level 3, GR-1089, GR-63 EN/ETSI 300 386-2 v1.1.3 (2000) Extreme Networks Consolidated Hardware Guide...
Page 339: Common Module Specifications
Table 119: Common module specifications Environmental Requirements Operating Temperature Storage Temperature Operating Humidity Extreme Networks Consolidated Hardware Guide 0° to 40° C (32° to 104° F) -40° to 70 ° C (-40° to 158° F) 10% to 95% relative humidity, noncondensing Common Module Specifications...
Page 340 Module Technical Specifications Extreme Networks Consolidated Hardware Guide...
Page 341 AC rear view, DC removing the chassis from a rack serial number telecommunications standard Extreme Networks Consolidated Hardware Guide Alpine 3804 switch AC power supply certification marks checking the installation checking the installation (AC) DC cabling...
Page 342 ANSI BISCI Extreme Networks Consolidated Hardware Guide 47, 55...
Page 343 BlackDiamond 6804 BlackDiamond 6808 checking the installation Alpine 3802 switch (AC) Alpine 3802 switch (DC) Alpine 3804 switch (AC) Alpine 3804 switch (DC) Alpine 3808 switch (AC) Alpine 3808 switch (DC) BlackDiamond switch Summit switch commands clear log static show memory...
Page 344 BlackDiamond 6808 switch installing in a BlackDiamond 6816 switch installing in an Alpine 3804 switch installing in an Alpine 3808 switch removing from a BlackDiamond 6804 switch removing from a BlackDiamond 6808 switch removing from a BlackDiamond 6816 switch...
Page 345 LX100 requirements removing safety specifications LX100 LX70 UTP GBIC ZX GBIC Extreme Networks Consolidated Hardware Guide GBIC (continued) ZX GBIC Rev 03 types UTP requirements GM-16T3 module dimensions electromagnetic compatibility environmental standard weight GM-16X3 module...
Page 346 ZX GBIC Rev 03 industry standards installation AC power cable retaining bracket, Summit switch AC power supply, Alpine 3804 switch AC power supply, Alpine 3808 switch Alpine 3802 chassis Alpine 3804 chassis Alpine 3804 fan tray Alpine 3808 chassis...
Page 347 Multi Protocol Label Switching Module, See MPLS module network processors ARM module ATM module MPLS module PoS module Extreme Networks Consolidated Hardware Guide operating environment requirements building codes electrical codes wiring closet optical interfaces Class 1 laser device (warning)
Page 348 (POST) Alpine 3802 switch (AC power) Alpine 3802 switch (DC) Alpine 3804 switch (AC power) Alpine 3804 switch (DC power) Alpine 3808 switch (AC power) Alpine 3808 switch (DC power) BlackDiamond 6800 series switch Summit switch rack specifications...
Page 349 Summit 200-48 switch agency certifications console port dimensions electromagnetic compatibility front view heat dissipation Extreme Networks Consolidated Hardware Guide Summit 200-48 switch (continued) 96, 99 laser safety LEDs MAC address port connections power socket power supply...
Page 350 SummitPx1 switch agency certifications connecting to console server dimensions electromagnetic compatibility front view Gigabit Ethernet port heat dissipation LEDs MAC address management port null modem cable Extreme Networks Consolidated Hardware Guide...
Page 351 Alpine 3804 AC power supply Alpine 3804 DC power supply Alpine 3804 fan tray installation Alpine 3804 fan tray removal Alpine 3808 AC power supply Alpine 3808 DC power supply Alpine 3808 fan tray installation Alpine 3808 fan tray removal...
Page 352 WM-1T3i module dimensions electromagnetic compatibility environmental standard telecommunications standard weight WM-4E1i module dimensions electromagnetic compatibility environmental standard telecommunications standard weight WM-4T1i module dimensions electromagnetic compatibility environmental standard telecommunications standard weight 37, 39 Extreme Networks Consolidated Hardware Guide...

This manual is also suitable for:

Summit summit48 Alpine 3802 Alpine 3804 Blackdiamond 6804 Blackdiamond 6808 Blackdiamond 6816 ... Show all

Extreme Networks Alpine 3808 Hardware Manual

Part 1 Common Features

Chapter 1 Summary of Common Switch Features

Part 2 Site Planning

Chapter 2 Site Preparation

Part 3 Summit Switch

Chapter 3 Summit Switch Overview

Chapter 4 Summit Switch Models

Summit48Si Power Supply Leds

Summit48Si Switch Bottom View

Summit1I, Summit5I, Summit7I, Summit48I, and Summit48Si Switch Leds

Summit4 Switch Front View

Summit4/Fx Switch Front View

Summit4 Switch Rear View

Summit4 Switch Leds

Summit24E2 Switch Front View

Summit24E2 Switch Rear View

Summit24E2 Switch Leds

Summit24E3 Switch Front View

Summit24E3 Switch Rear View

Summit24E3 Switch Leds

Summitpx1 Application Switch Front View

Chapter 5 Summit Switch Installation

Part 4 Alpine Switch

Chapter 6 Alpine 3800 Series Switch Overview

Following Safety Information

Alpine 3800 Series Architecture

Chapter 7 Alpine 3800 Series Switch Chassis

Installing the Chassis

Removing the Chassis

Chapter 8 Alpine 3800 Series Switch Power Supplies

Installing the Alpine 3808 and the Alpine 3804 AC Power Supply

Removing the Alpine 3808 and the Alpine 3804 AC Power Supply

Supplying Power to the Alpine 3802 AC Power Supply

Installing the Alpine 3808 and the Alpine 3804 DC Power Supply

Removing the Alpine 3808 and the Alpine 3804 DC Power Supply

Supplying Power to the Alpine 3802 DC Power Supply

Chapter 9 Alpine 3800 Series Switch Management Module

Installing Smmi Modules

Chapter 10 Alpine 3800 Series I/O Modules

Chapter 11 Alpine 3800 Series Switch Fan Tray

Part 5 Blackdiamond Switch

Chapter 12 Blackdiamond 6800 Series Switch Overview

Following Safety Information

Chapter 13 Blackdiamond 6800 Series Switch Chassis

Blackdiamond 6800 Series Architecture

Blackdiamond 6800 Series Architecture

Installing the Chassis

Rack Installation

Grounding the Blackdiamond 6800 Series Chassis

Removing the Chassis

Chapter 14 Blackdiamond 6800 Series Switch Power Supplies

Installing a Blackdiamond 6800 Series Power Supply

Removing a Blackdiamond 6800 Series Power Supply

Chapter 15 Blackdiamond 6800 Series Management Switch Module

Installing Msm64I Modules

Removing Msm64I Modules

Chapter 16 Blackdiamond 6800 Series I/O Modules

Configuring I/O Modules

Quick Links

Related Manuals for Extreme Networks Alpine 3808

Summary of Contents for Extreme Networks Alpine 3808
