6 Managing the System

Removing a CTI Link

o
Follow the procedure in the preceding topic,
the MLX
located.
o
When you have finished, file Form 2a with the rest of the planning forms.
o
To install the server-related hardware associated with the link, contact your
Lucent Technologies representative.
Programming Instructions
Console Procedure
PC Procedure
Removing a CTI Link
Use this procedure to remove the programming for a CTI (Computer Telephony
Integration) link from an MLX port on a 008 or 408 MLX module. This
hardware/software feature is available in Release 5.0 and later systems operating
in Hybrid/PBX mode.
NOTE:
This topic describes only the last steps in adding a CTI link to the system.
Additional LAN-related procedures are described in the PassageWay
Telephony Services Network Manager's Guide.
Task List: Removing a CTI Link
o
Obtain Form 2a, System Numbering: Extension Jacks.
o
Record the new values on Form 2a.
o
If necessary, read "Auxiliary Equipment" in System Programming , Chapter
4, for additional information.
o
Open the System Programming menu from the console or a PC with SPM.
o
Follow the procedure outlined in
Module'' on page 6-90
link is located.
o
Program the change(s), following the appropriate instructions for "Auxiliary
Equipment" in System Programming , Chapter 4, or the appropriate
summary programming instructions below.
o
Follow the procedure outlined in
Module'' on page 6-90
was located.
Module'', to restore service on the module where the CTI link is
AuxEquip CTI Link
Enter Exit
%
to terminate service on the module where the CTI
to restore service on the module where the CTI link
''Busying-Out and Restoring
6
Extension
Exit
Type ext. no.

6
6
''Busying-Out and Restoring the MLX
''Busying-Out and Restoring the MLX
Issue 1
June 1997
Page 6-92
Dial ext. no.
! !
