Lucent Technologies MERLIN LEGEND System Manager's Manual page 227

MERLIN LEGEND Communications System Release 5.0
System Manager's Guide 555-650-118
6 Managing the System
Introduction to System Programming
Table 6–2. System Programming Menu Options
Option Description
Set system operating conditions.
System
Select the system numbering plan and/or reassign extension numbers
SysRenumber
with 1- to 4-digit numbers.
Assign or remove operator positions and program operator features
Operator
(such as Operator Hold Timer or QCC options).
Program line/trunk options.
LinesTrunks
Program extensions (for example, with restrictions and lines).
Extensions
Program systemwide settings (for example, Transfer Return).
Options
Program features that require entering information in a table (such as
Tables
Allowed Lists and Disallowed Lists).
Program auxiliary equipment connected to the system (for example,
AuxEquip
loudspeaker paging and fax machines).
Program Night Service features.
NightSrvce
Program the labels shown on telephone displays (for example, entries
Labeling
in the System Directory and Posted Messages).
Specify extensions that need voice and data capability.
Data
Print system programming reports (for example, system configuration
Print
and extension assignments).
Perform centralized telephone programming (assign features to specific
Cntrl Prog
buttons on telephones).
Select the language of the system for MLX display telephones, SMDR
Language
reports, and print reports.
Saving Entries and Moving among Screens
At the bottom of each screen, one or more screen keys with functions allow you to
change or save your entry or return to a previous screen. Various combinations of
these keys appear on each programming screen.
Priority screen with a typical display of screen keys.
QCC Priority x:
Enter line/trunk number
xxx
Backspace
! Exit
Figure 6–5.
Delete
Next
Enter
Screen Keys
6
Figure 6–5
The QCC Queue Priority Level you
entered appears in place of
The line/trunk number you entered
appears in place of
$
%

Issue 1
June 1997
Page 6-9
shows the QCC
.
x
.
xxx
