MERLIN LEGEND Communications System Release 5.0
System Manager's Guide 555-650-118
6 Managing the System
Adding a CTI Link
To busy-out and then restore the MLX module, follow the steps below:
1. Use one of the following procedures. Note that you select the
option from the Main menu, not the System Programming menu.
Console Procedure
PC Procedure
The screen displays progress messages and informs you when the
busy-out is complete. Service on any facilities and/or extensions is
suspended.
2. Exit the Maintenance menu and return to the System Programming menu.
To add a CTI link, follow the procedures at the end of this topic. To remove
one, see
3. Restore the module to service. Use one of the following procedures:
Console Procedure
PC Procedure
The screen displays progress messages and informs you when the restore
is complete. Service resumes on affected facilities and/or extensions.
Task List: Adding a CTI Link
o
Obtain Form 2a, System Numbering: Extension Jacks.
o
Plan the CTI link addition using the planning guidelines above; record the
new values on Form 2a.
o
If necessary, read "Auxiliary Equipment" in System Programming , Chapter
4, for additional information.
o
Follow the procedure in the preceding topic, "Busying-Out and Restoring
the MLX Module," to terminate service on the module where the CTI link is
planned.
o
Open the System Programming menu from the console or a PC with SPM.
o
Program the change(s), following the appropriate instructions for "Auxiliary
Equipment" in System Programming , Chapter 4, or the appropriate
summary programming instructions below. To specify the CTI link
extension, use the main extension number (for example, extension 12 in a
2-digit numbering plan), not the adjunct extension number (for example,
extension 712 in a 2-digit plan).
To busy-out a module:
Menu
no.
Enter
To busy-out a module:
"
''Removing a CTI Link'' on page
To restore a module:
Menu
no.
Enter
To restore a module:
"
Maintenance Slot
Busy-Out Yes
Type slot no.

6-92.
Maintenance Slot
Restore Yes
Type slot no.

6
Issue 1
June 1997
Page 6-91
