MERLIN LEGEND Communications System Release 5.0
System Manager's Guide 555-650-118
6 Managing the System
Programming from a PC with SPM
Console/Display Instructions
If the PC does not have a hard disk, insert the SPM diskette into Drive A.

and press
Type
a:

appears on the screen.
A:>
Type and press
spm

Welcome to SPM
The MERLIN LEGEND
System Programming
& Maintenance Utility
Please press any key
to continue
Version X.XX
Press any key to display the SPM Main Menu shown below.

SPM Main Menu
Menu: Select Function

Sys Program
 Backup
 Boards
Print Opts
!
Monitor
If the SPM Main Menu does not appear or if the information about the
screen is garbled, press any key again.
If the COMM PORT (communications port) screen appears instead of the
SPM Main Menu, the SPM software has not been initialized. See Chapter 2
of System Programming.
To reach the System Programming menu, select

Perform the procedures in the task descriptions as outlined in this chapter.

.
P
to display the SPM Welcome screen shown below.
P
X.XX
"
Maintenance
Restore #
Pass-Thru $
%
Password

Language
NOTE:
The function keys shown on either side of the display are included
here for quick reference. On the PC screen, the system
programming keys do not look like actual keys.
Additional Information
= current version of SPM
Sys Program
Issue 1
June 1997
Page 6-20
by pressing .
