3 System Components
Telephones
MLX-5 telephones can be wall-mounted.
Direct Station Selector
The Direct Station Selector (DSS), shown in
can connect to an MLX-20L or an MLX-28D telephone programmed as an
operator console (it cannot connect to any other telephone). DSSs enhance the
capabilities of both DLCs and QCCs and, when connected to an MLX-20L
telephone, help with programming. The DSS has 50 multifunction buttons, all of
which have lights.
The system operator can use DSS buttons for one-touch dialing and Transfer.
Buttons can be programmed with the following numbers:
Extension numbers
Line/trunk numbers
Pool dial-out codes (Hybrid/PBX only)
Calling group extension numbers
Paging group extension numbers
Park zone access codes
Automatic Route Selection (ARS) access codes
Remote Access dial code
Listed Directory Number (the extension for the QCC queue)
replaces an MLX-10 or MLX-10D telephone, all line and feature
buttons must first be removed from the extension by centralized
telephone programming, so that "phantom buttons" do not exist for the
new telephone. Programming instructions come with the equipment.
3
Figure 3–10, is an adjunct that you
