MERLIN LEGEND Communications System Release 5.0
System Manager's Guide 555-650-118
3 System Components
Telephones
MLX-10
The MLX-10 telephone
10 line buttons that can be programmed with features
8 fixed-feature buttons
MLX-10 telephones can be wall-mounted.
Figure 3–8.
MLX-5D
The MLX-5D telephone
Display (2 lines by 24 characters)
5 line buttons that can be programmed with features
4 fixed display buttons, 4 unlabeled display buttons for screen selection,
and 8 fixed-feature buttons
NOTES:
1. The MLX-5D telephone should not be an operator console.
2. In Release 5.0 and later systems, the system recognizes the MLX-5D
(Figure
Handset
MLX-10
v
Volume
Feature
HFAI
Mute
Speaker
MLX-10 Telephone
(Figure
as a 5-button telephone. In releases prior to 5.0, the system recognizes
the MLX-5D as an MLX-10D. For this reason, when programming the
telephone, be careful not to assign lines or features to buttons that do
not actually exist on the telephone. When an MLX-5D telephone
3
3–8) provides the following features:
Button Labeling Card
Line Buttons (10)
Message Light
v
ABC DEF
1 2 3
Transfer MNO
GHI JKL
4 5 6
Dialpad
Conf
PQRS TUV WXYZ
7 8 9
Drop
OPER
Hold
* 0 #
Volume Control
Fixed-Feature Buttons (8)
User Cards and Tray
3
3–9) provides the following features:
Issue 1
June 1997
Page 3-20
