MERLIN LEGEND Communications System Release 5.0
System Manager's Guide 555-650-118
E
Removing/Reinstalling the Control Unit Cover
Installing the Control Unit Housing
Installing the Control Unit Housing
Installing the control unit housing involves two tasks: installing the top cover and
then installing the front cover.
This section contains instructions for both tasks.
Installing the Top Cover
To install the control unit top cover, see
1.
Be sure the cords have been pressed through the wire managers at the
base of the modules.
2.
Hold the top cover with the hooks facing you.
3.
Engage the tabs at the rear of the top cover with the carrier.
4.
Lower the top cover so that the legs lock into the vents on the module.
5
5
Figure E–2
and follow these steps:
Issue 1
June 1997
Page E-2
