Frame Format

Frame Format
Use this procedure to specify the framing format for the 100D module as
D4-compatible or Extended Superframe. Your selection must match the
framing mode at the far end of the DS1 facility.
Summary: Frame Format
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
All
100D module idle
Form 3b, Incoming
(100D module)
D4 compatible
D4, ESF
No
No
LinesTrunks LS/GS/DS1
Select format type
FrameFormat
Exit
[F4] [F1] Type slot no.
type [F10] [F1]
Trunks: DS1 Connectivity
Dial slot no.
Enter
[F10] [F2]
[F5]
DS1 Facilities 6-5
Enter
Exit
Select format
