Signaling

Signaling
Use this procedure to specify whether the type of dialing signal from the local
telephone company is touch-tone or rotary. Touch-tone dial mode cannot be
programmed for immediate-start DID trunks.
Touch-tone single-line telephone users cannot make calls by using individual
trunks programmed for rotary operation. The touch-tone signals generated
from the telephone while dialing are transmitted to the central office at the
same time the rotary signals are sent to the system. The central office
receives both signals and cannot process the call.
Summary: Signaling
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
8-8 DID Trunks
System manager
Hybrid/PBX
Not Required
Form 3d, incoming Trunks: DID
Rotary
Rotary, Touch-tone
No
No
LinesTrunks DID
Rotary or TouchTone
Enter
[F4] [F4] [F8]
[F2] [F10] [F5]
Signaling
Enter
Type trunk block no.
[F5]
Dial trunk block no.
Exit Exit
[F10] [F1] or
