AT&T MERLIN LEGEND Release 3.0 Programming Summary Manual page 127

B-Channel Groups
Summary: B-Channel Groups
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
Hybrid/PBX, Key
Not required
Form 3b, incoming Trunks: DS1 Connectivity
(100D module)
Not applicable
Group numbers (1 to 80)
Yes
No
To program a single line/trunk:
LinesTrunks PRI
group no.
Enter
Enter Lines
Dial line/trunk no.
To program a block of lines/trunks:
LinesTrunks PRI
group no.
Enter
Enter Lines
specific lines/trunks
Exit
To program a single line/trunk:
[F4] [F6] [F2]
channel slot and port nos.
[F10] [F6] Type line/trunk no.
To program a block of lines/trunks:
[F4] [F6] [F2]
channel slot and port nos.
[F10] Select specific lines/trunks
On/Off [F5] [F5]
B-ChannlGrp
Dial B-channel slot and port no.
Dial group no.
Enter
Enter Exit
B-ChannlGrp
Dial B-channel slot and port no.
Dial group no.
Enter
Toggle LED On/Off
[F1] Type group no
[F5] Type group no.
[F10]
[F1] Type group no
[F5] Type group no.
Toggle letter G
[F5]
Dial
B Channels
Entry Mode
Exit Exit
Dial
B Channels
Select
Exit Exit
Type B-
[F5] [F5] [F5]
Type B-
PRI Facilities 9-5
