Channel Service Unit

Channel Service Unit
Use this procedure to specify the type of equipment provided by the local
telephone company as foreign exchange or special access.
NOTE:
You do not need to use this procedure unless your system emulates loop-start
or ground-start with the T1 type of DS1 facility.
Summary: Channel Service Unit
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
6-10 DS1 Facilities
System manager
All
100D module idle
Form 3b, Incoming Trunks: DS1 Connectivity
(100D module)
Foreign Exchange
Foreign Exchange, Special Access
No
No
LinesTrunks LS/GS/DS1
Foreign Exchange or Special Access
ChannelUnit
Enter Exit Exit
[F4] [F1] Type slot no.
[F10] [F5] [F5]
Dial slot no.
Enter
[F10] [F8] [F1] or [F2]
