Clock Synchronization

Clock Synchronization
Use this procedure to specify the modules that provide primary, secondary,
and tertiary clock synchronization. (Contact your service provider for more
information about the appropriate setting.) You can also specify whether the
clock is synchronized to the external endpoint (loop) or to the clock reference
source (local). This procedure is also used to activate or deactivate the clock.
NOTE:
This procedure is necessary only if your system includes more than one
100D module.
Summary: Clock Synchronization
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
All
Not required
Form 3b, Incoming Trunks: DS1 Connectivity
(100D module)
Primary clock: the first 100D module in the control unit
carrier; source: loop; activation: active
Primary, Secondary, Tertiary, Loop/Local
No
No
LinesTrunks LS/GS/DS1
ClockSync Priority
Enter Source
Enter Activation
Exit Exit Exit
[F4] [F1] Type slot no.
clock synchronization
synchronization [F10]
[F10] [F5] [F5]
Dial slot no.
Select clock synchronization
Select source of synchronization
Select clock activation
[F10] [F7]
[F10] [F2]
[F3] Select clock activation
[F5]
Enter
Enter
[F1] Select
Select source of
DS1 Facilities 6-9
