Signaling Mode

Signaling Mode
Use this procedure to specify the signaling for the 100D module as robbed-bit
or common-channel signaling.
NOTE:
This procedure is needed only for T1 facilities; common-channel signaling is
set automatically for PRI facilities.
Summary: Signaling Mode
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
All
100D module idle
Form 3b, Incoming Trunks: DS1 Connectivity
(100D module)
Robbed bit
Robbed Bit, Common Channel
No
No
LinesTrunks LS/GS/DS1
Select type of signaling
Signaling
Exit
[F4] [F1] Type slot no.
signaling [F10] [F5]
Dial slot no.
Enter
[F10] [F4] Select type of
[F5]
DS1 Facilities 6-7
Enter
Exit
