9 Fixed Cycles: Contour Pocket with Contour Formula ..... 237
9.1 SL Cycles with Complex Contour Formula ..... 238
Basics ..... 238
Selecting a program with contour definitions ..... 240
Defining contour descriptions ..... 241
Entering a complex contour formula ..... 242
Overlapping contours ..... 243
Contour machining with SL Cycles ..... 245
9.2 SL Cycles with Simple Contour Formula ..... 249
Fundamentals ..... 249
Entering a simple contour formula ..... 251
Contour machining with SL Cycles ..... 251
HEIDENHAIN iTNC 530
29
