12 TOLL CALL 2 Z S5000
13 CYCL DEF 254 CIRCULAR SLOT
Q215=0
;MACHINING OPERATION
Q219=8
;SLOT WIDTH
Q368=0.2 ;ALLOWANCE FOR SIDE
Q375=70
;PITCH CIRCLE DIA.
Q367=0
;REF. SLOT POSITION
Q216=+50 ;CENTER IN 1ST AXIS
Q217=+50 ;CENTER IN 2ND AXIS
Q376=+45 ;STARTING ANGLE
Q248=90
;ANGULAR LENGTH
Q378=180 ;STEPPING ANGLE
Q377=2
;NUMBER OF OPERATIONS
Q207=500 ;FEED RATE FOR MILLING
Q351=+1
;CLIMB OR UP-CUT
Q201=-20 ;DEPTH
Q202=5
;PLUNGING DEPTH
Q369=0.1 ;ALLOWANCE FOR FLOOR
Q206=150 ;FEED RATE FOR PLUNGING
Q338=5
;INFEED FOR FINISHING
Q200=2
;SETUP CLEARANCE
Q203=+0
;SURFACE COORDINATE
Q204=50
;2ND SETUP CLEARANCE
Q366=1
;PLUNGE
14 CYCL CALL FMAX M3
15 L Z+250 R0 FMAX M2
16 END PGM C210 MM
170
Call slotting mill
Define SLOT cycle
No pre-positioning in X/Y required
Starting point for 2nd slot
Call SLOT cycle
Retract in the tool axis, end program
Fixed Cycles: Pocket Milling / Stud Milling / Slot Milling
