Q204=0 ;2ND SETUP CLEARANCE
Q211=0.2 ;DWELL TIME AT DEPTH
10 CYCL CALL PAT F5000 M3
11 L Z+100 R0 FMAX M6
12 TOOL CALL 2 Z S5000
13 L Z+10 R0 F5000
14 CYCL DEF 200 DRILLING
Q200=2 ;SETUP CLEARANCE
Q201=-25 ;DEPTH
Q206=150 ;FEED RATE FOR PECKING
Q202=5 ;PLUNGING DEPTH
Q210=0 ;DWELL TIME AT TOP
Q203=+0 ;SURFACE COORDINATE
Q204=0 ;2ND SETUP CLEARANCE
Q211=0.2 ;DWELL TIME AT DEPTH
15 CYCL CALL PAT F5000 M3
16 L Z+100 R0 FMAX M6
17 TOOL CALL 3 Z S200
18 L Z+50 R0 FMAX
19 CYCL DEF 206 TAPPING NEW
Q200=2 ;SETUP CLEARANCE
Q201=-25 ;DEPTH OF THREAD
Q206=150 ;FEED RATE FOR PECKING
Q211=0 ;DWELL TIME AT DEPTH
Q203=+0 ;SURFACE COORDINATE
Q204=0 ;2ND SETUP CLEARANCE
20 CYCL CALL PAT F5000 M3
21 L Z+100 R0 FMAX M2
22 END PGM 1 MM
HEIDENHAIN iTNC 530
0 must be entered here, effective as defined in point table
Cycle call in connection with point table TAB1.PNT
Feed rate between points: 5000 mm/min
Retract the tool, change the tool
Call tool: drill
Move tool to clearance height (enter a value for F)
Cycle definition: drilling
0 must be entered here, effective as defined in point table
0 must be entered here, effective as defined in point table
Cycle call in connection with point table TAB1.PNT
Retract the tool, change the tool
Tool call for tap
Move tool to clearance height
Cycle definition for tapping
0 must be entered here, effective as defined in point table
0 must be entered here, effective as defined in point table
Cycle call in connection with point table TAB1.PNT
Retract in the tool axis, end program
