HEIDENHAIN ITNC 530 - CYCLE PROGRAMMING User Manual page 512

Cycle
Cycle designation
number
420 Workpiece—measure angle
421 Workpiece—measure hole (center and diameter of hole)
422 Workpiece—measure circle from outside (diameter of circular stud)
423 Workpiece—measure rectangle from inside
424 Workpiece—measure rectangle from outside
425 Workpiece—measure inside width (slot)
426 Workpiece—measure outside width (ridge)
427 Workpiece—measure in any selectable axis
430 Workpiece—measure bolt hole circle
431 Workpiece—measure plane
440 Measure axis shift
441 Rapid probing: Set global touch probe parameters (FCL 2 function)
450 KinematicsOpt: Save kinematics (option)
451 KinematicsOpt: Measure kinematics (option)
452 KinematicsOpt: Preset compensation (option)
460 Calibrate TS: Radius and length calibration on a calibration sphere
480 Calibrate the TT
481 Measure/Inspect the tool length
482 Measure/Inspect the tool radius
483 Measure/Inspect the tool length and the tool radius
484 Calibrate infrared TT
512
DEF CALL
Page
active active
Page 405
Page 408
Page 412
Page 416
Page 420
Page 424
Page 427
Page 430
Page 433
Page 433
Page 453
Page 456
Page 464
Page 466
Page 466
Page 458
Page 499
Page 501
Page 503
Page 505
Page 500
