New Cycle Functions of Software
340 49x-03
New cycle for setting a datum in the center of a slot (see "SLOT
CENTER REF PT (Cycle 408, DIN/ISO: G408, FCL 3 Function)" on
page 345)
New cycle for setting a datum in the center of a ridge (see "RIDGE
CENTER REF PT (Cycle 409, DIN/ISO: G409, FCL 3 function)" on
page 349)
New 3-D probing cycle (see "MEASURING IN 3-D (Cycle 4, FCL 3
function)" on page 451)
Cycle 401 now also allows you to compensate workpiece
misalignment by rotating the rotary table (see "BASIC ROTATION
from Two Holes (Cycle 401, DIN/ISO: G401)" on page 325)
Cycle 402 now also allows you to compensate workpiece
misalignment by rotating the rotary table (see "BASIC ROTATION
over Two Studs (Cycle 402, DIN/ISO: G402)" on page 328)
In the cycles for datum setting, the results of measurement are
available in the Q parameters Q15X (see "Measurement results in Q
parameters" on page 399)
