3.8 UNIVERSAL PECKING (Cycle 205,
DIN/ISO: G205)
Cycle run
1 The TNC positions the tool in the tool axis at rapid traverse FMAX to
the programmed setup clearance above the workpiece surface.
2 If you enter a deepened starting point, the TNC moves at the
defined positioning feed rate to the setup clearance above the
deepened starting point.
3 The tool drills to the first plunging depth at the programmed feed
rate F.
4 If you have programmed chip breaking, the tool then retracts by
the entered retraction value. If you are working without chip
breaking, the tool is moved at rapid traverse to the setup
clearance, and then at FMAX to the entered starting position above
the first plunging depth.
5 The tool then advances with another infeed at the programmed
feed rate. If programmed, the plunging depth is decreased after
each infeed by the decrement.
6 The TNC repeats this process (2 to 4) until the programmed total
hole depth is reached.
7 The tool remains at the hole bottom—if programmed—for the
entered dwell time to cut free, and then retracts to the setup
clearance at the retraction feed rate. If programmed, the tool
moves to the 2nd setup clearance at FMAX.
HEIDENHAIN iTNC 530
91
