Effect of coordinate transformations
Beginning of effect: A coordinate transformation becomes effective as
soon as it is defined—it is not called. It remains in effect until it is
changed or canceled.
To cancel coordinate transformations:
Define cycles for basic behavior with a new value, such as scaling
factor 1.0
Execute a miscellaneous function M2, M30, or an END PGM block
(depending on MP7300).
Select a new program
Program miscellaneous function M142 "Erasing modal program
information".
HEIDENHAIN iTNC 530
273
