Web-based Configuration Guide
Table 3-1 Wi-Fi Configuration Parameters
Parameter
SSID
SSID Encoding
Purpose
Band
Encryption
Wi-Fi Password
Select server group
Wi-Fi Standard
Wireless Schedule
VLAN
Description
Enter the name displayed when a wireless client searches for a wireless
network.
The SSID encoding standard is set to "UTF-8" by default when Chinese
characters are included in the SSID. If the Chinese characters are garbled, you
can choose "GB2312" as the SSID encoding standard.
Set the Wi-Fi usage scenario. The options include General, IoT, and Guest.
The system will recommend different Wi-Fi parameter combinations based on
the selected purpose.
Set the band used by the Wi-Fi signal. The options are 2.4 GHz and 5 GHz. The
5 GHz band provides faster network transmission rate and less interference than
the 2.4 GHz band, but is inferior to the 2.4 GHz band in terms of signal coverage
range and wall penetration performance. Select a proper band based on actual
needs. The default value is 2.4G + 5G, indicating that the device provides
signals at both 2.4 GHz and 5 GHz bands.
The encryption options for a Wi-Fi network include Open, Security, and 802.1x
(Enterprise).
When the Security is set to WEP, you need to set the password for connecting
to the wireless network. The password is a string of 8 to 63 characters.
When the Encryption is set to 802. 1x (Enterprise), you need to configure a
remote server set for authentication and authorization.
The Wi-Fi standards include 802.11be (Wi-Fi 7), 802.11ax (Wi-Fi 6), or
Compatibility Mode. The final effective Wi-Fi standard depends on the support
of Wi-Fi standards on each device. The latest standard is recommended. If there
is a compatibility issue, try use an older standard. However, an old standard
setting will affect the bandwidth.
Specify the time periods during which Wi-Fi is enabled. After you set this
parameter, users cannot connect to Wi-Fi in other periods.
Set the VLAN to which the Wi-Fi signal belongs. You can choose from the
available VLANs or click Add New VLAN, and go to the LAN Settings page to
add a VLAN.
25
Wi-Fi Network Settings
