Ruijie RG-RAP73Pro Cookbook page 168

Web-based Configuration Guide
Parameter
Lease Time (Min)
4.5 Configuring Repeater Mode
4.5.1 Wired Repeater
Choose One-Device. Click the device mode, and then choose Config > Network > Work Mode.
Connect a network cable from the WAN port (uplink LAN port) of the device to the upper-layer device.
Select Access Point, click Check, confirm the Wi-Fi settings of the AP, and then click Save to expand the
network coverage.
Caution
After the configuration is saved, connected clients will be disconnected from the network for a short period of
time. You can reconnect the clients to the Wi-Fi network for restoration.
4.5.2 Wireless Repeater
The wireless repeater mode extends the Wi-Fi coverage range of the primary device. The device supports the
dual-link wireless repeater mode and can extend both 2.4 GHz and 5 GHz signals of the primary device.
Note

To avoid loops in wireless repeater mode, remove the network cable from the WAN port.

Obtain the Wi-Fi name and Wi-Fi password of the upper-layer router.
Choose One-Device. Click the device mode, and then choose Config > Network > Work Mode.
Description
Lease time of the automatically assigned IP addresses. When the lease
time expires, devices on the LAN will obtain IP addresses again.
113
Network Settings
