Ruijie RG-RAP73Pro Cookbook page 21

Installation Guide
3.3 Installing the AP
Note

In an indoor environment, a ceiling-mounted AP offer broader antenna radiation coverage compared to a
wall-mounted one. Hence, ceiling mounting is the preferred option.

The schematic diagram provided is for reference purposes only. The actual product should be installed
based on its physical specifications and design.
(1) Drill holes on the ceiling or wall using the mounting template.
(2) Use four Phillips head screws to secure the mounting plate to the ceiling or wall.
13
Installing the AP
