Ruijie RG-RAP73Pro Cookbook page 218

Web-based Configuration Guide
According to the user's application scenario, the requirements are shown in the following table:
Table 6-10 User Requirement Specification
Item
IP address and port number
Version
Community name/User name

Configuration Steps
(1) Select the v2c version in the Trap Setting interface and click Save.
(2) Click Add in the Trap v1/v2c Client List to add a trap v2c user.
(3) Enter the destination host IP address, version, port number, user name, and other information. Then, click
OK.
Description
The destination host IP is 192.168.110.85, and the port number is 166.
Select the v2c version.
Trap_ruijie
163
System Settings
