- Page 1 Ruijie Reyee RG-RAP1201 Access Point Hardware Installation and Reference Guide Document Version: V1.0 Date: 2023-07-28 Copyright © 2023 Ruijie Networks...
- Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
-
Page 3: Preface
Preface Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee Technical support website: https://ruijienetworks.com/support Case portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ... - Page 4 Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation. Note An alert that contains additional or supplementary information that if not understood or followed will not lead to serious consequences. Specification An alert that contains a description of product or version support.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Product Overview ..........................1 1.1 Package Contents ........................1 1.2 Product Appearance ........................ 2 1.2.1 Front Panel ........................2 1.2.2 Rear Panel ........................3 1.3 Technical Specifications ......................4 1.4 Power Module Technical Specifications ................. 6 1.5 Cooling ............................ - Page 6 3.2 Safety Precautions........................11 3.3 Installing the AP ........................12 3.4 Bundling Cables........................13 3.5 Verifying Installation ......................13 4 Verifying the Operating Status ..................... 15 4.1 Setting up the Environment ....................15 4.2 Powering on the AP ........................ 15 4.2.1 Checking Before Power-On ..................
- Page 7 7.2 List of Hazardous Substances (10 Years)................20...
-
Page 8: Product Overview
Hardware Installation and Reference Guide Product Overview Product Overview Package Contents Table 1-1 Package Contents Item Quantity RG-RAP1201 access point Protective cover Phillips pan head screws (M4 x 20 mm) Quick installation guide Warranty manual Note The package contents above are intended to provide a general overview, and are subject to the terms of the order contract. -
Page 9: Product Appearance
Hardware Installation and Reference Guide Product Overview Product Appearance 1.2.1 Front Panel Figure 1-1 Front Panel Table 1-2 LEDs Mark Item Status Description The access point is NOT receiving power. Fast blinking (blinks eight times per The access point is starting up. second) Steady white The access point is functioning properly. -
Page 10: Rear Panel
Hardware Installation and Reference Guide Product Overview Table 1-3 Ports and Buttons on the Front Panel Mark Item Description LAN port 10/100/1000 Base-T Ethernet port for wired connection Stick the pin to the Reset hole: Restart the access point. Reset hole Press and hold the pin to the Reset hole for more than 5 seconds: Restore the access point to factory settings. -
Page 11: Technical Specifications
Hardware Installation and Reference Guide Product Overview Technical Specifications Table 1-5 Specifications Radio Design 2.4 GHz and 5 GHz dual-radio dual-stream Protocol and Supports both 802.11ac wave2/wave1 and 802.11a/b/g/n Standard standards for simultaneous operation Operating 802.11b/g/n: 2.4 GHz-2.4835 GHz Band 802.11a/n/ac: 5.150 GHz-5.350 GHz, 5.470 GHz-5.725 GHz, 5.725 GHz-5.850 GHz Antenna... - Page 12 Hardware Installation and Reference Guide Product Overview 802.11ac: HT80: -76 dBm (MCS 0), and -51dBm (MCS 9) Max. Transmit 2.4 GHz ≤ 20 dBm Power 5 GHz ≤ 30 dBm Note The transmitted power may vary based on local laws and regulations.
-
Page 13: Power Module Technical Specifications
Hardware Installation and Reference Guide Product Overview Installation In-wall mounting Compliance MTBF > 400000 hrs Power Module Technical Specifications The RG-RAP1201 wall-plate wireless access point is compatible with PoE (Power over Ethernet) standards 802.3at and 802.3bt. To power this access point using PoE, make sure that the PSE supports IEEE 802.3af power supply. -
Page 14: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid personal injury and device damage, carefully read the safety precautions before you install the device. The following safety precautions may not cover all possible dangers. ... -
Page 15: Cleanliness
Hardware Installation and Reference Guide Preparing for Installation other hand, low humidity can cause shrinkage of insulation gaskets and looseness of fastening screws, which can generate static electricity and pose a risk to internal circuits, especially in dry climate environments. High temperature can significantly impact the reliability and service life of the device by accelerating the aging process of insulation materials. -
Page 16: Esd Protection
Hardware Installation and Reference Guide Preparing for Installation Table 2-3 Requirements for Gases Avg. (mg/m Max. (mg/m Sulfur dioxide 0.006 0.03 Hydrogen sulfide (H 0.04 0.15 Nitrogen dioxide (NO 0.05 0.15 Ammonia gas (NH 0.01 Chlorine gas (CI 2.2.3 ESD Protection The RG-RAP1201 wall plate wireless access point has been designed with rigorous anti- static procedures during circuit design. -
Page 17: Mounting Workbench
Hardware Installation and Reference Guide Preparing for Installation radio transmitting stations and radar launchers. 2.2.5 Mounting Workbench When installing the device on a wall, the following conditions must be met: The wall surface must be smooth and clean. The network cables must be in good condition. ... -
Page 18: Installing The Ap
Hardware Installation and Reference Guide Installing the AP Installing the AP Caution Before installing the AP, make sure that you have carefully read the requirements described in Chapter 2. Before You Begin Carefully plan and arrange the installation location, networking mode, power supply, and cabling before installation. -
Page 19: Installing The Ap
Hardware Installation and Reference Guide Installing the AP Keep the device clean and dust-free. Cut off the power before cleaning the device. Do not wipe the device with a damp cloth. Do not wash the device with liquid. ... -
Page 20: Bundling Cables
Hardware Installation and Reference Guide Installing the AP (4) Install the protective cover on the device. The installation process is complete. Bundling Cables Precautions Bundle the cables in a visually pleasing way. Bend twisted pairs naturally or to a large radius close to the connector. ... - Page 21 Hardware Installation and Reference Guide Installing the AP Verify that the twisted pair cable matches the port type. Verify that cables are properly bundled. Verify that the PSE device is 802.3af-compliant. ...
-
Page 22: Verifying The Operating Status
Hardware Installation and Reference Guide Verifying the Operating Status Verifying the Operating Status Setting up the Environment When powering the device through PoE (Power over Ethernet), ensure that the power cord is properly connected and meets safety requirements. Powering on the AP 4.2.1 Checking Before Power-On Verify that the PSE device connected to the WAN/PoE port of the device is 802.3af-... -
Page 23: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring You can monitor the device in operation by observing its LED. Hardware Maintenance If the hardware is faulty, please contact Ruijie Networks technical support. -
Page 24: Troubleshooting
Check whether the power supply is properly connected. Check whether the LED is normal. Check whether cables are properly connected with ports. Contact Ruijie technical support to check whether hardware faults exist. Finish Common Faults 6.2.1 The LED Is Off After the Device is Powered On Check whether the PSE connected to the WAN/ PoE port is 802.3af-compliant, and... -
Page 25: A Sta Cannot Discover The Ap
Hardware Installation and Reference Guide Troubleshooting 6.2.3 A STA Cannot Discover the AP (1) Verify that the AP is properly powered. (2) Verify that the Ethernet port is correctly connected. (3) Verify that the AP is correctly configured. (4) Move the client closer to the AP. -
Page 26: Appendix
Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T port The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, 1000BASE-T requires Category 5e 100-ohm UTP or STP (recommended) with a maximum distance of 100 meters (328 feet). The 1000BASE-T port requires all four pairs of wires to be connected for data transmission. - Page 27 Hardware Installation and Reference Guide Appendix Table 7-1 100BASE-TX/10BASE-T Pin Assignments Socket Plug Input Receive Data+ Output Transmit Data+ Input Receive Data- Output Transmit Data- Output Transmit Data+ Input Receive Data+ Output Transmit Data- Input Receive Data- 4, 5, 7, 8 Not Used Not Used The following figure shows feasible connections of the straight-through and crossover...
- Page 28 GB/T 26572. 2. This table shows the components, in which hazardous substances are found in Ruijie products. Depending on the model, products may not contain all of the above components. The actual model you purchased shall prevail.
