Web-based Configuration Guide
Table 6-7 User Requirement Specification
Item
View range
Group configuration
Configuring v3 Users
Version

Configuration Steps
(1) On the global configuration interface, select v3, and change the port number to 161. Set other settings to
defaults. Then, click Save.
(2) Add a view on the View/Group/Community/Client Access Control interface.
a Click Add in the View List pane.
b Enter the view name and OID in the pop-up window, and click Add Included Rule.
c Click OK.
Description
Included rule: the OID is .1.3.6.1.2.1, and the custom view name is
"public_view".
Group name: group
Security level: authentication and encryption
Select public_view for a read-only view.
Select public_view for a read & write view.
Select none for a notify view.
User name: v3_user
Group name: group
Security level: authentication and encryption
Authentication protocol/password: MD5/Ruijie123
Encryption protocol/password: AES/Ruijie123
For SNMP v3, the default port number is 161.
156
System Settings
