Ruijie RG-RAP73Pro Cookbook page 14

Installation Guide
Power Step
Dimensions (W X D
X H)
Weight
Service Ports
Management Port
Status LED
Power Supply
Options
Max. Power
Consumption
Temperature
Humidity
Certification
MTBF
1.5 Power Supply Technical Specifications
The RG-RAP73Pro can be powered by the DC power supply or PoE.

When a DC power adapter is used for power supply, the power adapter with a voltage of 54 V and a current
of 0.55 A or higher provided by Ruijie needs to be used, which needs to be purchased separately from Ruijie.

When the AP is powered by PoE, the Ethernet cable must be connected to the LAN/2.5G/PoE port of the AP,
and the other end of the Ethernet cable must be connected to the PoE-capable switch port or a PoE power
sourcing equipment. Ensure that the power sourcing equipment supports IEEE 802.3at.
1.6 Cooling
The RG-RAP73Pro adopts a fanless design.
1 dBm
220 mm x 220 mm x 45 mm (8.66 in. x 8.66 in. x 1.77 in.) (excluding the mounting
plate)
≤ 1.1 kg (2.43 lbs.)
1 x 100/1000/2500BAST-T port with auto-negotiation, supporting PoE input
1 x 1G/10GBASE-X SFP+ port (SFP+ optical transceiver module is optional)
Note
The RG-RAP73Pro does not transmit optical signals. An optical transceiver
module must be installed on the access point to convert optical signals into
electrical signals.
N/A
1 x system status LED (blue)
Local power supply through a DC power adapter with a current of 54 V and 0.55
A or higher
IEEE 802.3at-compliant PoE
< 30 W
Operating temperature: 0° C to 40° C (32° F to 104° F)
Storage temperature: –40° C to +70° C (–40° F to +158° F)
Operating humidity: 5% RH to 95% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
CE, RoHS, FCC, ISED, cTUVus
> 400000 hours
6
Product Overview
