Ruijie RG-RAP73Pro Cookbook page 130

Web-based Configuration Guide
Parameter
Authentication Device
Network
SSID
Seamless Online
Seamless Online Period
Portal Page
3. Adding a Voucher
(1) Log in to Ruijie Cloud, choose Project > Auth & Accounts > Accounts > User Management, and select a
network in this account.
(2) Configure a user group.
a On the User Group tab, click Add.
Description
Indicates the device that performs the authentication.
When there is a router on the network, you are advised to enable
authentication on the router. You can perform authentication on either an
access point (AP) or a router.
AP: An AP acts as the N/AS.
Router: A router or gateway acts as the N/AS responsible for performing
authentication at the gateway exit.
AP Authentication: RAP, ReyeeOS 1.219 or later version.
This parameter is not required if the policy mode is Local.
Indicates the wired network that requires authentication. Enter the network
segment in this field.
Users connecting to the wired network corresponding to this network segment
must be authenticated.
This parameter is required if the Authentication Device is Router.
Indicates the network name of the Wi-Fi network that requires authentication.
Users connecting to this wireless network must be authenticated.
This parameter is required if the Authentication Device is AP.
After this function is enabled, if the first authentication is successful,
subsequent connections to this Wi-Fi network will automatically be
authenticated within a certain period of time.
Indicates the time period for seamless online. If the first authentication is
successful, subsequent connections to this Wi-Fi network will automatically be
authenticated within this period of time.
Indicates the portal page that is displayed after portal authentication.
Click Current Project to select the portal page for an existing project.
Click Shared Portals to select an existing portal page.
Click Add Page to customize a portal page.
75
Wi-Fi Network Settings
