7.2.10 D
IAGNOSTICS
Press the "Diagnostics" item or the respective button
device:
• operating status, i.e. whether the device communicates correctly with the Switchboard
application ("Device Status" tab, see
• firmware version and alignment, i.e. which firmware version the device has and whether it is
aligned with the same software development platform present on the Switchboard application
("Firmware Alignment" tab, see
• configuration file alignment, i.e. whether the configuration file on each device is aligned with the
configuration file on the Switchboard application ("Configuration Alignment" tab, see
Any anomalies on the "Diagnostics" (incorrect communication or misalignment of one or more
devices) are highlighted by the Switchboard application by means of acoustic and visual signals
(the icon
The devices must be put in the configuration, so that the "Diagnostics" function can report any
anomalies
The tabs described above are shown in the figure below (which shows a part of the screen which
appears when you press the "Diagnostics" item or the respective button):
The individual tabs are described in greater detail below.
86
Figure
starts flashing red).
Figure 82: diagnostics screen tab
to display the following information for each
Figure 83);
84);
Figure 85).
