7.5.3 V
IEWING MAPS
Press "View" --> "Maps" or the respective button
described in the previous paragraphs. The following screen opens:
The navigation module is on the left of the page and the imported planimetries with highlighted
"sensitive" areas are present in the central part of each node.
The area with the list of devices to be placed on the maps is not present, they were positioned
already during the construction of the maps themselves.
DS1060-121G
(if present on the button bar) to view that
Figure 113: site map view
