External Application Configuration - urmet domus iPercom 1060 Installation And User Manual

where it is possible to display all active chats with switchboard.
The reception of a new chat message is signalled visually (by its icon that starts flashing green) and
acoustically.
If the Switchboard application is in the background on the screen of your PC, the operator can still
see a possible chat message arrival signal through the relative icon that is brought to the
foreground enlarged and turns green for about 2s.
This functionality was already explained in paragraph
7.2.8 E
XTERNAL APPLICATION CONFIGURATION
This feature allows choosing an application on your own PC and running it from Switchboard application
by means of button (if enabled on button bar, see paragraph
from menu "Tools" item "External application config", the following window appears:
"Browse" button allows choosing the application to be executed (normally an exe file) with its path.
In the second textfield it is possible to enter the path of a file to be opened with the application
previously chosen.
The "OK" button can be used to save the previously entered data.
"Clear" button allows deleting what selected previously.
In this way on Switchboard application button bar (if enabled) clicking on
selected application is executed or the related file is opened with the selected application.
84
Chat
Figure 80: external application configuration
list.
Button bar configuration). Clicking
button (if enabled), the
DS1060-121G
